Elvox 6680 - Page 6

7
13
1
CHCH CH 6S53
7
4
3
2
5
6
10
8
9
12
11
21V
V1
M
V3
V2
6E
6
6S
6P
C
A
1
AU
3
5
2
V3
CH
CN1 CN2
+
+D
+A
-
CN1
V1
M
V2
M
CH 6S5321V
PRI
V1M1 3AUM2V2
1
C2 2
A
B
+
-
S76-8AM+T 015 S1 C1
D
C
L1
A
7
B
+T
M
V
8
CT
3
4
6
CH
7
2
1
5
6
3
4
12
10
11
8
9
M
13
V
ELVOX
6
"SOUND SYSTEM" SINGLE AND MULTIPLE RESIDENCE VIDEO DOOR ENTRY SYSTEM WITH POWER SUPPLY
TYPE 6680 AND WITHOUT CONVERSATION PRIVACY
MONITOR CABLE RISER
B/W MONITOR
type 6300
type 6301
type 6500
type 6501
POWER SUPPLY
type 6680
N.B.
In the event of buzzing on the
audio line, move the switching
module "A-B" located under the
cover to position "A".
Mains
A- Video entrance panel
GALILEO SECURITY, GALILEO, 8100
PATAVIUM and letter box 2550/301-302 series
B- Additional door lock button
C- 12V~ electric lock
D- Camera with speech unit
type 559, 559A, 559B, 559G, 558, 570,
570G, 571, 559C and 570C+930A
Note: For the connection of camera type 559A
and 559B see variation 17
L1- entrance panel illumination bulb
(3x24V 3W max.)
10x24V 3W with type M832
16X24V 3W with type 832/030
DIAGRAM N° vc4306R1
B/W MONITOR
type 6000 +
type 6200 +
type 6145
Connect 75 Ohm resistor (sup-
plied) to the last monitor, between
terminals V2-M.
*
*
COLOUR
MONITOR
type 6003 +
type 6200 +
type 6145
COLOUR MONITOR
type 6303
N.B.
The monitors have a microswitch
on the back, set it to “without con-
versation privacy”.
N.B.
The monitors have a microswitch
on the back (or underneath) for
connection "with coaxial/without
coaxial"; set the microswitch to
"coaxial".
CABLE
type 61/001
type 61/003
CABLE
type 61/001
type 61/003
* *
* *
*
The “CONVERSATION PRI-
VACY” function is normally deac-
tivated. To activate or deactivate
the function see conversation pri-
vacy programming.
COLOUR MONITOR
type 6600
* *
* *
*
