Intercommunicating call pushbutton programming
Programming phase:
1) Raise
the handset of the interphone/video interphone to call
(when using series 8870, Giotto, Petrarca). With other versions of
series 6600 (without handset) press and keep pressed the
talk/listen push-button .
2) Remove the cover of the interphone to be programmed.
3) Press and hold the RESET push-button on the audio door entry unit to
program.
4) Press and hold the additional pushbutton to make the intercommuni-
cating call together with the RESET pushbutton.
5) Release the RESET pushbutton, keeping the call pushbutton pressed.
6) After 2 seconds the interphone emits a high tone, while the other in-
terphone emits a 3-tone ascending scale.
7) Release the intercommunicating call pushbutton.
8) On the interphone called (with the 3-tone ring), press one of the pro-
grammed pushbuttons (such as lock, F1, F2 or actuator).
9) A high tone confirms the end of the procedure.
Repeat the same procedure for the other interphones and any other inter-
communicating call pushbuttons.
Programming the self-start pushbutton to a specific panel.
Programming phase:
1) Remove the interphone cover.
2) Press and hold the RESET pushbutton on the interphone.
3) Press and hold the additional pushbutton to activate the self-start fun-
ction together with the RESET pushbutton.
4) Release the RESET pushbutton, keeping the self-start pushbutton
pressed.
5) After 2 seconds the interphone emits a high tone.
6) Release the self-start pushbutton.
7) On pushbutton entrance panels, press the call button for the inter-
phone, while on alphanumeric keypads, enter the call code and press
pushbutton “ ”.
8) A high tone confirms the end of the procedure.
Restoring default values of pushbuttons
(P2,P3,P4,P5,P6,P7,P8)
Programming phase:
1) Remove the interphone cover.
2) Press and hold the RESET pushbutton on the interphone.
3) Press and hold the relative pushbutton to be reprogrammed together
with the RESET pushbutton.
4) Release the RESET pushbutton, keeping the other pushbutton pressed.
5) After 2 seconds the interphone emits a high tone.
6) Release the pushbutton to restore to default and then press again.
Deleting all settings.
Programming phase:
This procedure is advised when you want to change the ID of an inter-
phone/monitor previously programmed and you do not want keep the ope-
ration programming of the appliance.
1) Remove the interphone cover.
2) Press and hold the RESET pushbutton on the interphone.
3) Press and hold the self start pushbutton together with the RESET pu-
shbutton.
4) Release the RESET pushbutton, keeping the self-start pushbutton
pressed.
5) After 2 seconds the interphone emits a continuous tone for two se-
conds.
6) Release the self-start pushbutton.
7) During the continuous tone, press the tab on the lock release pushbut-
ton.
If the deletion procedure is successful, when the lock release tab is
pressed once more the interphone emits a triple “Beep”.
Secondary identification code programming
Programming of the secondary identification code is only required when
more than one interphone is to be called by means of the same pushbut-
ton or call code. The interphones that ring at the same time are associa-
ted with the same group. The “master” interphone is programmed first by
means of the “identification code programming” procedure described
above, while the additional group interphones are programmed with the
secondary identification code (see table page 44).
A maximum of three audio door entry units plus one group master can
be associated with the same group, without the need for programmer
Type 950C or SaveProg .
If the interphones are combined with Petrarca monitors, an additional
power supply type 6923 must be fitted for each additional monitor
after the second monitor. Using programmer type 950C, activation of
the ringtone on all monitors can be programmed, without simultane-
ous activation of all monitors, to then enable activation of the moni-
tor from the interphone used to answer the call with the self-start
pushbutton; this avoids the need to use additional power supplies.
Programming phase:
1) Remove the interphone cover.
2) Press and hold the RESET pushbutton on the interphone.
3) Press and hold the tab on the lock release pushbutton and the self
start/auto-activation pushbutton (the first pushbutton below the tab),
together with the RESET pushbutton.
4) Release the RESET pushbutton, keeping the other two pushbuttons
pressed.
5) After 2 seconds the interphone emits a high tone and communication
is enabled with the panel. If the monitor is also connected to the inter-
phone, it is switched on and connected to the camera of the entrance
panel.
6) Release the tab on the lock release pushbutton and the self start pu-
shbutton.
7) On pushbutton entrance panels, press the call button for the “master”
interphone, while on alphanumeric keypads, enter the call code of the
“master” interphone and press pushbutton “ ”.
8) When the secondary code is associated with the interphone and com-
munication is terminated.
To know the number assigned see table shown in the wiring diagram section.
Pushbutton programming
The interphone is supplied with a pair of additional pushbuttons type 692P,
for the functions self start and the auxiliary service “stair light”, which ac-
tivates the 1st relay of the 1st actuator (type 692R), if connected to the sy-
stem. A further three pairs of pushbuttons type 692P can be inserted in
the interphone, to be connected to connectors T2-T3-T4, corresponding to
the following default functions.
Pushbutton Connector In program. Default function
1° T1 P1 Self-start
2° T1 P2 Stair light (1st relay of 1st
actuator, type 692R)
3° T2 P3 Auxiliary (2nd relay of 1st
actuator, type 692R)
4° T2 P4 Not associated
5° T3 P5 Not associated
6° T3 P6 Not associated
7° T4 P7 Function F1 on panel
8° T4 P8 Function F2 on panel
P0 is the lock button.
To change the operating mode of buttons P0 and P1, use programmer type
950C or the Save Prog software.
