2. CONNECTIONS&CONTROLS
2.4 FRONTPANELEA460-300XT
1 RCAINPUTS1/2-CH
  Low-levelstereoRCAsignalinputforconnectionwithhead-unit.
2 RCAINPUTS3/4-CH
  Low-levelstereoRCAsignalinputforconnectionwithhead-unit.
3 INPUTGAINCONTROL1/2-CH
  Inputgaincontrolfor1/2-CHamplifiersection-allowingtomatchtheoutputvoltage
ofthehead-unit‘sRCAline-outstotheamplifierinputsection.
4 OPERATIONMODESWITCH1/2-CH
  Switchtoselecttheoperationmodeoftheelectroniccrossoverdriving1/2-CHsection
oftheamplifier.
5 CROSSOVERFREQUENCYCONTROL1/2-CH
  Crossovercontrolpotentiometerforthefrequencyadjustmentofthe12dB/oct.high-
passorlow-passfilterforCH1/2.
6 INPUTGAINCONTROL3/4-CH
  Inputgaincontrolfor3/4-CHamplifiersection-allowingtomatchtheoutputvoltage
ofthehead-unit‘sRCAline-outstotheamplifierinputsection.
7 OPERATIONMODESWITCH3/4-CH
  Switchtoselecttheoperationmodeoftheelectroniccrossoverdriving3/4-CHsection
oftheamplifier.
8 CROSSOVERFREQUENCYCONTROL3/4-CH
  Crossovercontrolpotentiometerforthefrequencyadjustmentofthe12dB/oct.high-
passorlow-passfilterforCH3/4.
9 REMOTELEVELPORT5-CH
  Telephonejackinputsocketforconnectionwiththedash-mountedlevel
remoteunit.
10 PHASECONTROL5-CH
  PhasecontrolpotentiometerfortherelativephaseadjustmentofCH5.
11 INPUTGAINCONTROL5-CH
  Inputgaincontrolfor5-CHamplifiersection-allowingtomatchtheoutputvoltageof
thehead-unit‘sRCAline-outstotheamplifierinputsection.
