2.CONNECTIONS&CONTROLS
2.2FRONTPANELEA2250XT
1 RCAINPUTS
  Low-levelstereoRCAsignalinputforconnectionwithline-outofthe
  head-unit(sub-out).
2 INPUTGAINCONTROL
  Inputgaincontrolpotentiometer,allowingtomatchtheoutputvoltageoftheheadunit’s
RCAline-outstotheamplifierinputsection.
3 SUBSONICCROSSOVERFREQUENCYCONTROL
  Crossover control potentiometer for the frequency adjustment of the 12 dB/oct.
subsonichigh-passfilter.
4 HIGHPASSFREQUENCYCONTROL
  Crossovercontrolpotentiometerforthefrequencyadjustmentofthe12dB/oct.
high-passfilter.
5 OPERATIONMODESWITCH
  Switchtoselecttheoperationmodeoftheelectroniccrossoverdrivingtheamplifier
channel(s).
6 LOWPASSCROSSOVERFREQUENCYCONTROL
  Crossovercontrolpotentiometerforthefrequencyadjustmentofthe12dB/oct.low-
passfilter.
7 REMOTELEVELPORT
  Connectdash-mountedlevelremoteunitviatelephonejackinputsocket.
2 3 4 5
6
7
1
