EM Phaser EA1450XT - Page 7

7
2. CONNECTIONS&CONTROLS
2.1REARPANELEA1450XT
8 POWERLED/PROTECTIONLED
  GreenPower-LED,signalingcorrectoperationoftheamplifier.Red“protection”LED,
signalingfaultyspeakerconnectionsorgeneralmalfunctionoftheamplifier.
9 GNDPOWERINPUTTERMINAL
  Mouldeddirectpowerinputterminaltoconnecttheamplifiertothenegativeorground
wireofthevehicle.
10 REMOTEINPUTTERMINAL
  Terminaltoconnecttheamplifiertotheautomatic(remote)turn-on/turn-offleadofthe
head-unit.
11 +12VPOWERINPUTTERMINAL
  Mouldeddirectpowerinputterminaltoconnecttheamplifiertothepositive+12V
powerwireconnectedtothecarbattery.
12 FUSE
  80AmpereMaxifuse.
13 SPEAKERTERMINALS
  Moulded loudspeaker output terminals to connect loudspeakers. The Mono Amp
EA1450XTfeaturestwoparallelPlusandtwoMinuspoles.
8 9 1210 11 13
