EM Phaser EA1450XT - Page 14

14
2. CONNECTIONS&CONTROLS
2.4 REARPANELEA460-300XT
16 POWERLED/PROTECTIONLED
  Red„protection“LED,signalingfaultyspeakerconnectionsorgeneralmalfunctionof
  theamplifier.GreenPower-LED,signalingcorrectoperationoftheamplifier.
17 GNDPOWERINPUTTERMINAL
  Mouldeddirectpowerinputterminaltoconnecttheamplifiertothenegativeorground
poleofthecarbattery.
18 REMREMOTEINPUTTERMINAL
  Terminaltoconnecttheamplifiertotheautomatic(remote)turn-on/turn-offleadof
thehead-unit.
19 +12VPOWERINPUTTERMINAL
  Mouldeddirectpowerinputterminaltoconnecttheamplifiertothepositive+12V
poleofthecarbattery.
20 FUSE
  80AmpereMaxifuse
21 SPEAKEROUTPUTTERMINALS1/2-CH
  Outputterminaltoconnectthespeakerstothe1/2-CHchannelsoftheamplifier.
22 SPEAKEROUTPUTTERMINALS3/4-CH
  Outputterminaltoconnectthespeakerstothe3/4-CHchannelsoftheamplifier.
23 SPEAKEROUTPUTTERMINALS5-CH
  Outputterminaltoconnectthespeakerstothe5-CHmonochanneloftheamplifier.
16 23
22
2017 18 19 21
