Congratulations!
on your purchase of this sophisticated EMPHASER ECP-XT4 2-way component system. If you plan
on installing the ECP-XT4 component system by yourself, please read the following instructions
carefully before you attempt the installation. For any further information about this product, please
contact your EMPHASER dealer.
TECHNICAL DESIGN FEATURES
MID/WOOFER
■
13 / 16.5 CM EURO-DIN ALUMINUM CAST BASKET
■
STRONTIUM-FERRITE MAGNET
■
WOVEN BLACK KEVLAR
™
CONE
■
MBR BUTYL RUBBER DOUBLE-ROLL SURROUND
■
PROGRESSIVE BLACK NOMEX
™
SPIDER
■
INVERTED ALUMINUM DUSTCAP
■
2-LAYER COPPER CLAD ALUMINUM WIRE VOICE COIL
■
36 / 25 MM
Ø
POLYIMIDE VOICE COIL FORMER
■
VENTED CAVITY BELOW SPIDER
■
VENTED & EXTENDED CENTER POLE
■
SCREW TERMINAL BINDING POSTS
■
INSULATED TINSEL LEAD WIRES
TWEETER ECP-XT4
■
25 MM SOFT DOME TWEETER
■
COATED SILK DOME
■
CCAW WIRE VOICE COIL ON AL-FORMER
■
NDFEB NEODYMIUM MAGNET MOTOR
■
CAST ALUMINUM TWEETER HOUSING
■
FLAT- AND FLUSH MOUNTING ADAPTORS INCLUDED
■
LOW VISCOSITY FERROFLUID
CROSSOVER ECP25XT4
■
TWEETER ATTENUATION BY 4-POSITION JUMPER
■
GLASFIBER EPOXY CIRCUIT BOARD
■
MKP POLYPROPYLENE METAL-FILM CAPACITOR
■
LOW TOLERANCE METAL-OXIDE RESISTORS
■
LOW RESISTANCE AIR CORE INDUCTORS
■
OSRAM HPCCR LAMP TWEETER PROTECTION
