Unpacking
Check the packaging for signs of damage in transit. Any damage should be reported immediately to the
transportation company and the local representative.
Lift the coupling NX out of its packaging. Place the test system so that there is sufficient free space around the
cooling air inlets on both sides and behind the fan outlet on the rear panel.
Using the following list, check that all the items ordered have been delivered:
1. coupling NX-series CDN
2. Safety manual (only one per delivery)
3. 1 Power mains cable for the coupler supply, country coded
4. 1 HVS – Banana – Banana, 0.3 m (3HU) or 0.5 m (6HU) HV cable, 1 x red, 1 x black
5. 1 BCC 350 – Coax – Coax, 0.4 Meter HV cable SHV - SHV
6. 1 SLC 500 Sys Link Cable, 0.5 Meter, NX5 to compact NX5
7. 1 3-phase EUT supply input cable, 2.0 Meter, 3* black, 1* blue, 1* yegn
8. 1 ESA2, EUT supply adapter 1 phase country coded and 3 phase 16 A or 32 A
9. Earth connection, 0.3 m brass bar including mounting parts (screws M4 x 10)
10. Earth connection, 0.3 m brass bar, mounting parts has to be prepared and mounted by the user
11. User manual (pdf on the delivered memory stick)
12. Optional items, as ordered
If additional equipment is ordered
- SLC xxx ;Sys Link Cable with various cable length
Check the equipment for signs of transport damage. Any damage should be reported to the Transportation
Company and local representative immediately.
