EM TEST UCS 500 Series
Operating Manual V 3.05 51 / 57
12.2. Quick Start
Easy and very fast operation of all standard functions of the equipment. The last simulator settings are stored
automatically and will be recalled with the next selecting of Quick Start.
Page 3 (show parameters)
ESD Quickstart
V = 6000V +/- = -
Mod = CD tr = 1s
tri = single n = 10
START CHANGE
F1 F2 F3 F4 F5 F6 F7
Press START and the test routines begin to work.
Press CHANGE and the actual parameters can be changed.
12.3. Standard test routines
Within this test routine all standard parameters can be changed online during testing. This procedure therefore is
very easy and fast to use.
Page 3 (show parameters)
ESD standard routine IEC 61000-4-2
+4000V AD Single 010
Counter
START +/- O V/E Mode Trig 0
F1 F2 F3 F4 F5 F6 F7
Definitions:
- Mode Air discharge AD
Contact discharge CD
- Trigger Single : Single discharge after pushing TEST ON at the P18
CONT : Continuos discharge after pushing TEST ON at the P18
AUTO : Continuos discharge after pushing the function key F1.
Attention: The TEST ON button at the P18 needs not to be pushed
O V/Ev. Either the test voltage V or the number of events can be selected for adjust
