19” LCD Color Monitor Emachine E19T5W
10
2. DVI-D connector
Pin No. Description Pin No. Description
1.
TMDS data 2－
15. GND
2.
TMDS data 2＋
16. Hot Plug Detect
3. TMDS data 2/4 Shield 17.
TMDS data 0－
4. NA 18.
TMDS data 0＋
5. NA 19. TMDS data 0/5 Shield
6. DDC Clock 20. NA
7. DDC Data 21. NA
8. Analog Vertical Sync 22. TMDS Clock Shield
9.
TMDS data 1－
23. TMDS Clock +
10.
TMDS data 1＋
24.
TMDS Clock －
11. TMDS data 1/3 Shield C1 Analog red
12. NA C2 Analog Horizontal Sync
13. NA C3 Analog blue
14.
＋5V Power
C4 Analog Horizontal Sync
24 - Pin Color Display Signal Cable
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
C1 C2
C3 C4
