19” LCD Color Monitor Emachine E19T5W
16
5.2 Electrical Block Diagram
5.2.1 Main Board
EEPROM
M24C02
(U404)
EEPROM
M24C16
(U403)
Panel Interface
(CN101)
SDA
SCL
Crystal
14.318MHZ
(X401)
Flash Memory
SST25LF020A
(U402)
Scalar TSUM56AWHK
(Include MCU, ADC, OSD)
(U401)
H sync
V sync
RGB
VGA_SDA,
VGA
_
SCL
DVI_SDA,
DVI_SCL
D-Data
D-Clock
DVI
Connector
(CN406)
EEPROM
M24C02
(U405)
D-Sub
Connector
(CN405)
Key Control
Interface
(CN403)
