EN 21HOW TO USE THE MACHINE
To start the engine it will be necessary that:
– the transmission is in “neutral”;
– the blades are not engaged;
– the operator is seated or the parking brake is engaged.
The engine stops when:
– the operator leaves his seat when the blades are engaged;
– the operator leaves his seat when the transmission is not in “neutral”;
– the operator leaves his seat with the transmission in “neutral” but without enga-
ging the parking brake;
– the grass-catcher is lifted or the stone-guard is removed when the blades are
engaged
The table below shows various operating conditions, highlighting why the safety
device shuts down the engine.
OPERATOR GR.-CATCHER BLADES TRANSMISSION BRAKE ENGINE PILOT LAMPS
A) PILOT LAMPS ON (Key in «ON» position)
Sitting YES Disengaged «N» Engaged Stopped
Sitting NO Disengaged «N» Disengaged Stopped
B) WHEN STARTING (Key in «START» position)
Sitting –/– Disengaged 1...5 - F / R Engaged Does NOT start
Sitting –/– Engaged «N» Engaged Does NOT start
Absent –/– Disengaged «N» Disengaged Does NOT start
Sitting –/– Disengaged «N» Engaged Starts
Sitting –/– Disengaged «N» Disengaged Starts
Absent –/– Disengaged «N» Engaged Starts
C) WHEN MOVING ONLY (Key in «ON» position)
Sitting –/– Disengaged 1...5 - F / R Disengaged Running
Absent –/– Disengaged «N» Engaged Running
Sitting YES Disengaged 1...5 - F / R Engaged Stops
Absent YES Disengaged «N» Disengaged Stops
D) WHEN CUTTING (Key in «ON» position)
Sitting YES Engaged –/– Disengaged Running
Sitting NO Disengaged –/– Disengaged Running
Absent –/– Disengaged «N» Engaged Running
Sitting NO Engaged –/– Disengaged Stops
Absent YES Disengaged «N» Disengaged Stops
Absent YES Engaged –/– Engaged Stops
