LOADING
AIRPLANE
OPERATIONS
MANUAL
1-07-70
Page
4
Code
02
REVISION 38
AOM-145/1114
PACKAGE SIZE TABLE
The table below shows the approximate rectangular package
maximum dimensions which will pass through the baggage door
without interference with the baggage door, airplane fuselage or
compartment interior.
Enter the table with the package width and height and read the
maximum length of the package that can be stowed in the baggage
compartment.
NOTE: This table was calculated not considering the cart stowage unit
on the baggage compartment.
WIDTH – in cm
5 10 15 20 25 30 35 40
12.7 25.4 38.1 50.8 63.5 76.2 88.9 101.6
Height
in cm
MAXIMUM PACKAGE LENGTH – in cm
5 104 97 95 90 85 75 60 45
12.7 264.16 246.38 241.3 228.6 215.9 190.5 152.4 114.3
8 104 97 95 90 85 75 60 45
20.32 264.16 246.38 241.3 228.6 215.9 190.5 152.4 114.3
10 104 97 95 90 85 75 60 45
25.4 264.16 246.38 241.3 228.6 215.9 190.5 152.4 114.3
13 104 97 95 90 85 75 60 45
33.02 264.16 246.38 241.3 228.6 215.9 190.5 152.4 114.3
16 104 97 95 90 85 75 60 45
40.64 264.16 246.38 241.3 228.6 215.9 190.5 152.4 114.3
19 100 97 95 90 85 75 60 45
48.26 254 246.38 241.3 228.6 215.9 190.5 152.4 114.3
22 100 97 95 90 80 70 60 45
55.88 254 246.38 241.3 228.6 203.2 177.8 152.4 114.3
25 100 97 95 90 80 70 60 45
63.5 254 246.38 241.3 228.6 203.2 177.8 152.4 114.3
28 100 97 95 90 80 70 60 45
71.12 254 246.38 241.3 228.6 203.2 177.8 152.4 114.3
31 100 97 95 90 80 70 60 45
78.74 254 246.38 241.3 228.6 203.2 177.8 152.4 114.3
34 100 97 95 90 80 70 60 45
86.36 254 246.38 241.3 228.6 203.2 177.8 152.4 114.3
