Embraer EMB145 - Page 1087

CONFIGURATION
DEVIATION
LIST
AIRPLANE
OPERATIONS
MANUAL
1-08-06
Page
2
Code
01
REVISION 36
AOM-145/1114
System & 1. 2. Number installed
Sequence ITEM 3. Number required for dispatch
Number 4. Remarks and/or exceptions
6 DIMENSIONS AND
AREAS
41-7 Red Beacon Fairing
(192EL - Figure 2)
1 0 May be missing provided
maximum airspeed is limited
to 250 KIAS/0.65 M,
whichever is lower.
41-8 Hydraulic Servicing
Access Door
(193DL/EL/FL - Figure 2)
(193GR/HR/JR - Figure 3)
6 0 May be missing provided
maximum airspeed is limited
to 250 KIAS/0.65 M,
whichever is lower
41-9 Fuel Tank Drain Valve
Access Door
(192CL - Figure 2, 4)
(192DR - Figure 3, 5)
2 0 May be missing provided
maximum airspeed is limited
to 250 KIAS/0.65 M,
whichever is lower.
41-10 Fuel Wing Stub Drain
Valve Access Door
(192HL - Figure 4)
(192JR - Figure 5)
(EMB-145 LR and XR)
2 1 One may be missing with no
penalty.
41-11 Drip Stick Door
(192FL - Figure 4)
(192GR - Figure 5)
(EMB-145 LR and XR)
2 1 One may be missing with no
penalty.
41-12 Pneumatic Duct
Joints Access Panel
(193SL/XL - Figure 4)
(193YR/TR - Figure 5)
4 0 May be missing provided
maximum airspeed is limited
to 250 KIAS/0.65 M,
whichever is lower.
41-13 Hydraulic System
Service Access Door
(193WL - Figure 4)
(193ZR - Figure 5)
2 0 May be missing provided
maximum airspeed is limited
to 250 KIAS/0.65 M,
whichever is lower.
