NOTE: 1) Turbulence detection is only available on the PRIMUS®
880.
2) When target alert is enabled and a level 3 weather return is
detected in the forward 15° antenna scan, TGT in amber is
displayed.
3) TX is displayed in amber when the airplane is on ground
and WX is transmitting, but not selected for display, or in
STBY and FSTBY.
4) Early version of the P1000 annunciates TX in amber when
the radar is in the warm up mode. In later versions the warm
up is indicated by WAIT in green.
5) When weather radar is invalid WX in amber is displayed.
6) When on the ground and the weather test display is
selected, weather failures are indicated by fault codes in the
tilt angle field.
4 - WEATHER RADAR TGT/VAR ANNUNCIATORS
− When the target alert mode is armed, the message TGT in
green appears. It turns amber when a potentially dangerous
target is detected. This indicates that the pilot should select a
higher range on the weather radar to view the target. When
variable radar gain is selected, VAR in amber is displayed.
5 - DME HOLD ANNUNCIATOR
− If DME hold is selected when VOR is displayed, H in amber is
displayed.
6 - FMS HEADING (FHDG) ANNUNCIATOR
− When heading guidance is supplied from the FMS, FHDG in
magenta is displayed.
7 - FMS STATUS ANNUNCIATOR
The following FMS status annunciators are displayed in amber:
− INTEG (Integrity) - The GPS sensor does not meet the required
integrity calculations for the current phase of flight.
− WPT (Waypoint) - The airplane is approaching a flightplan
waypoint.
− DR (Dead reckoning) - The FMS is in dead reckoning mode.
− DGR (Degrade) - The ability of the FMS to accurately calculate
airplane position is degraded.
