The following FMS status annunciators are displayed in cyan:
− SXTK (Crosstrack) - The airplane is off track.
− TERM (Terminal) - The FMS is in the terminal phase of the
flightplan.
− APP (Approach) - the FMS is in the approach phase of the
flightplan. For RNAV (FMS) approaches, the annunciator is
displayed steady and for GPS approaches, the annunciator flashes
for ten seconds.
The table below shows the Full-scale Deviation for FMS Terminal and
Approach Modes:
ANNUNCIATOR
(IN CYAN)
MODE
FULL-SCALE
LATERAL
DEVIATION
FULL-SCALE
VERTICAL
DEVIATION
APP GPS Approach 0.3 NM 150 ft
APP (steady) RNAV
Approach
1.25 NM 150 ft
TERM GPS Terminal 1.0 NM 500 ft
AIRSPEED DISPLAY
When the FGS enters the MAX SPEED mode, the annunciator MAX
SPEED is displayed in amber to the left of the ADI sphere.
