Embraer EMB145 - Page 399

AIRPLANE
OPERATIONS
MANUAL
NORMAL PROCEDURES
REVISION 36
1-02-95
Page
17
Code
05
AOM-145/1114
EM145AOM021011A.DGN
AIRPLANE
ATTITUDE
(DEGREES)
P
(FEET)
R
(FEET)
3,0
3,8
13,7
10,0
4,3 14,1 10,42,5
GLIDE SLOPE
ANGLE
(DEGREES)
R
P
GLIDE SLOPE PATH
GLIDE SLOPE
ANGLE
P − HEIGHT OF THE PILOT’S EYE ABOVE THE WHEELS R − HEIGHT OF GLIDE RECEIVER ANTENNA ABOVE THE WHEELS
GROUND
CAT II APPROACH GEOMETRY AT
DECISION HEIGHT
EMB−135
23°0’
14°4’
PILOT EYE POSITION
HORIZONTAL REFERENCE
JAA
FLAPS 22°
