NORMAL PROCEDURES
AIRPLANE
OPERATIONS
MANUAL
1-02-95
Page
18
Code
05
REVISION 36
AOM-145/1114
EM145AOM021010A.DGN
AIRPLANE
ATTITUDE
(DEGREES)
P
(FEET)
R
(FEET)
3,0
5,3
15,2
11,8
5,8 15,6 12,22,5
GLIDE SLOPE
ANGLE
(DEGREES)
R
P
GLIDE SLOPE PATH
GLIDE SLOPE
ANGLE
P − HEIGHT OF THE PILOT’S EYE ABOVE THE WHEELS R − HEIGHT OF GLIDE RECEIVER ANTENNA ABOVE THE WHEELS
GROUND
CAT II APPROACH GEOMETRY AT
DECISION HEIGHT
EMB−145
23°0’
14°4’
PILOT EYE POSITION
HORIZONTAL REFERENCE
FAA/CTA
FLAPS 22°
