Embraer EMB145 - Page 944

WEIGHT AND BALANCE
145 140 135 LB
AIRPLANE
OPERATIONS
MANUAL
1-06-15
Page
6
Code
02
REVISION 37
AOM-145/1114
EMB-145 XR Model:
Wing Tank
FUEL CATEGORY
VOLUME
(US Gal)
WEIGHT
(lb)
CG BALANCE ARM
(in)
UNUSABLE UNDRAINABLE
2.6 17.6 580.31
UNUSABLE DRAINABLE
9.0 60.8 580.31
TOTAL UNUSABLE
11.6 78.4 580.31
USABLE
1689.8 11434.8 596.57
Ventral Tank
FUEL CATEGORY
VOLUME
(US Gal)
WEIGHT
(lb)
CG BALANCE ARM
(in)
UNUSABLE UNDRAINABLE
0.7 5.0 678.43
UNUSABLE DRAINABLE
2.4 16.1 680.63
TOTAL UNUSABLE
3.1 21.1 680.91
USABLE
275.3 1862.7 696.38
NOTE: The values above have been determined for an adopted fuel
density of 6.767 lb/US Gal.
FUEL QUANTITIES (ERJ-140 MODELS)
ERJ-140 ER Model:
FUEL CATEGORY
VOLUME
(US Gal)
WEIGHT
(lb)
CG BALANCE ARM
(in)
UNUSABLE UNDRAINABLE
1.6 11 544.29
UNUSABLE DRAINABLE
12.6 85 544.29
TOTAL UNUSABLE
14.2 96 544.29
USABLE
1359.6 9200 567.60
