Embraer EMB145 - Page 945

AIRPLANE
OPERATIONS
MANUAL
WEIGHT AND BALANCE
145 140 135 LB
REVISION 37
1-06-15
Page
7
Code
02
AOM-145/1114
ERJ-140 LR Model:
FUEL CATEGORY
VOLUME
(US Gal)
WEIGHT
(lb)
CG BALANCE ARM
(in)
UNUSABLE UNDRAINABLE
2.6 17.6 544.29
UNUSABLE DRAINABLE
9.0 60.8 544.29
TOTAL UNUSABLE
11.6 78.4 544.29
USABLE
1689.8 11434.8 560.55
NOTE: Fuel density may range from 6.550 to 6.770 lb/US Gal. The
values above have been determined for an adopted fuel
density of 6.767 lb/US Gal.
FUEL QUANTITIES (EMB-135 MODELS)
EMB-135 ER Model:
FUEL CATEGORY
VOLUME
(US Gal)
WEIGHT
(lb)
CG BALANCE ARM
(in)
UNUSABLE UNDRAINABLE
1.6 11 501.34
UNUSABLE DRAINABLE
12.6 85 501.34
TOTAL UNUSABLE
14.2 96 501.34
USABLE
1359.6 9200 524.65
EMB-135 LR Model:
FUEL CATEGORY
VOLUME
(US Gal)
WEIGHT
(lb)
CG BALANCE ARM
(in)
UNUSABLE UNDRAINABLE
2.6 17.6 501.34
UNUSABLE DRAINABLE
9.0 60.8 501.34
TOTAL UNUSABLE
11.6 78.4 501.34
USABLE
1689.8 11434.8 518.00
NOTE: Fuel density may range from 6.550 to 6.770 lb/US Gal. The
values above have been determined for an adopted fuel
density of 6.767 lb/US Gal.
