Emelson SL Series - Technical Specifications; Appliance Specifications; Safety Warnings

- 5 -
Specifications:
Name
Gas-fired instantaneous water heater
Model
EMLCLE10SLGB
Heat Input （Hi） Q
21kW
Heat Output P
19.5kW
Max flow rate
10L/min
Appliance Type
C
13
,B
23
Type of Gas
I2H-G20-20mbar
I3P-G31-37mbar
I3B/P-G30-29mbar
Max water pressure
Pw=10bar
Min water pressure
Pw=0.2bar
Electrical power supply
230v a.c. 50Hz
Insulation grade
Class I
Electrical and water protection
IPX4D， IPX0 (when installed as type B23)
Ignition method
Water control automatic pulse ignition
Temperature control method
Gas proportional valve automatic control
Destination country
AT-BE-CH-DE-DK-ES-FI-FR-GB-GR-IE-IT-NL-PT-NO-SE
Pipe joint
Gas inlet
G1/2 or G3/4
Water inlet
G1/2
Water outlet
G1/2
Exhaust pipe
Φ100(external), Φ60(internal)
WARNING:
 Read the technical instructions before installing the appliance.
 Read the user’s instructions before lighting the appliance.
