Emerson Dixell XR70T User Manual

1592040000 XR20-30-60-70T EN v1.5 2021.06.22 XR20-30-60-70T 22/41
dEF
od2
Optimized defrost
no
Pr2
n(0); Y(1)
dEF
dSt
Temperature sampling time during an
optimized defrost (valid only if od2=yes)
30
Pr2
sec
1 to 255 sec
dEF
SYd
Type of synchronized defrost
nU
Pr2
nu(0); SYn(1); nSY(2)
dEF
dt1
Differential temperature for latent heating
control
0.1
Pr2
°C
0.1 to 1.0°C
dEF
ErS
Restart regulation after dripping time, when
defrost Syd = nSY
no
Pr2
n(0); Y(1)
FAn
FAP
Probe selection for evaporator fan
P2
Pr2
nP(0); P1(1); P2(2); P3(3); P4(4)
FAn
FSt
Evaporator fan stop temperature
10.0
Pr2
°C
[-50.0°C to 50.0°C]
[-58.0°F to 122.0°F]
FAn
HYF
Evaporator fan regulator differential
2.0
Pr2
°C
[0.1°C to 25.0 °C]
[0.1°F to 45.0°F]
FAn
FnC
Evaporator fan operating mode
C_n
Pr2
C-n(0); O-n(1); C-Y(2); O-Y(3)
FAn
Fnd
Evaporator fan delay after defrost cycle
1
Pr2
min
0 to 255 min
FAn
FCt
Differential temperature for cyclic activation
of evaporator fans (o=disabled)
0
Pr2
°C
[0°C to 50°C]
[0°F to 90°F]
FAn
FSU
Evaporator fan operating mode
Std
Pr2
Std(0); FoF(1); Fon(2)
FAn
Ft
Evaporator fan controlled during defrost
no
Pr2
n(0); Y(1)
FAn
Fon
Evaporator fan ON time in normal mode
(with compressor OFF)
5
Pr2
min
0 to 255 min
FAn
FoF
Evaporator fan OFF time in normal mode
(with compressor OFF)
10
Pr2
min
0 to 255 min
FAn
Fo1
Evaporator fan ON time in energy saving
mode (with compressor OFF)
5
Pr2
min
0 to 255 min
FAn
FF1
Evaporator fan OFF time in energy saving
mode (with compressor OFF)
10
Pr2
min
0 to 255 min
FAn
Fd1
Evaporator fan delay
0
Pr2
sec
0 to 255 sec
FAn
Fd2
Evaporator fan delay after closing door
0
Pr2
sec
0 to 255 sec
FAn
FAC
Probe selection for condenser fan
P3
Pr2
nP(0); P1(1); P2(2); P3(3); P4(4)
FAn
St2
Set Point 2 regulation (for condenser fan)
10.0
Pr2
°C
[-100.0°C to 150.0°C]
[-148.0°F to 302.0°F]
FAn
Hy2
Set Point 2 differential (for condenser fan)
10.0
Pr2
°C
[0.1°C to 25.0°C]
[0.1°F to 45.0°F]
FAn
FCC
Condenser fan operating mode
C_n
Pr2
C-n(0); O-n(1); C-Y(2); O-Y(3)
FAn
Fd3
Condenser fan activation delay
0
Pr2
sec
0 to 255 sec
FAn
Fd4
Condenser fan deactivation delay
0
Pr2
sec
0 to 255 sec
AUS
ACH
Type of control for auxiliary regulator
CL
Pr2
CL(0); Ht(1)
AUS
SAA
Set point for auxiliary regulator
5.0
Pr2
°C
[-100.0°C to 150.0°C]
[-148.0°F to 302.0°F]
AUS
SHy
Auxiliary regulator differential
2.0
Pr2
°C
[0.1°C to 25.0°C]
[0.1°F to 45.0°F]
AUS
ArP
Probe selection for auxiliary regulator
nP
Pr2
nP(0); P1(1); P2(2); P3(3); P4(4)
AUS
Sdd
Auxiliary regulator disabled during any
defrost cycle
no
Pr2
n(0); Y(1)
AUS
btA
Base time for parameters Ato and AtF
SEC
Pr2
SEC; Min
AUS
Ato
Interval of time with auxiliary output ON
0
Pr2
sec
0 to 255 sec/min
AUS
AtF
Interval of time with auxiliary output OFF
0
Pr2
sec
0 to 255 sec/min
ALr
ALP
Probe selection for temperature alarms
P1
Pr1
nP(0); P1(1); P2(2); P3(3); P4(4)
ALr
ALC
Temperature alarms configuration: relative,
absolute
Ab
Pr1
rE(0); Ab(1)
ALr
ALU
High temperature alarm
150.0
Pr1
°C
°C[0.0° to 50.0° or ALL to
150.0°]
°F[0.0° to 90.0° or ALL to 302.0°]
