Emerson Dixell XR70T User Manual

1592040000 XR20-30-60-70T EN v1.5 2021.06.22 XR20-30-60-70T 23/41
ALr
ALL
Low temperature alarm
-100.0
Pr1
°C
°C[0.0° to 50.0° or -100.0° to
ALU]
°F[0.0° to 90.0° or -148.0° to
ALU]
ALr
AFH
Temperature alarm differential
2.0
Pr1
°C
[0.1°C to 25.0°C]
[0.1°F to 45.0°F]
ALr
ALd
Temperature alarm delay
0
Pr1
min
0 to 255 min
ALr
dot
Temperature alarm delay with open door
00:00
Pr1
mm:ss
0.0 to 24min00sec
ALr
dAo
Temperature alarm delay at start-up
00:00
Pr1
hh:mm
0.0 to 24h00min
ALr
AP2
Probe selection for second temperature
alarm
P2
Pr2
nP(0); P1(1); P2(2); P3(3); P4(4)
ALr
AU1
Pre-alarm threshold for second
temperature alarm (absolute value)
150.0
Pr2
°C
[-100.0°C to 150.0°C]
[-148.0°F to 302.0°F]
ALr
AH1
Second high temperature pre-alarm
differential
2.0
Pr2
°C
[0.1°C to 25.0°C]
[0.1°F to 45.0°F]
ALr
Ad1
Second high temperature pre-alarm delay
255
Pr2
min
0 to 255 min
ALr
AL2
Second low temperature alarm
-100.0
Pr2
°C
[-100.0°C to 150.0°C]
[-148.0°F to 302.0°F]
ALr
AU2
Second high temperature alarm
150.0
Pr2
°C
[-100.0°C to 150.0°C]
[-148.0°F to 302.0°F]
ALr
AH2
Second temperature alarm differential
2.0
Pr2
°C
[0.1°C to 25.0°C]
[0.1°F to 45.0°F]
ALr
Ad2
Second temperature alarm delay
0
Pr2
min
0 to 255 min
ALr
dA2
Second temperature alarm delay at start-
up
00:00
Pr2
hh:mm
0.0 to 24h00min
ALr
bLL
Compressor OFF due to second low
temperature alarm
no
Pr2
n(0); Y(1)
ALr
AC2
Compressor OFF due to second high
temperature alarm
n
Pr2
n(0); Y(1); MAn(2)
ALr
SAF
Differential for anti-freezing control
-1.0
Pr2
°C
[-12.0°C to 12.0°C]
[-21.6°F to 21.6°F]
ALr
tbA
Alarm relay deactivation
no
Pr2
n(0); Y(1)
oUt
oA2
Relay output oA2 configuration
dEF
Pr2
nu(0); CP1(1); dEF(2); FAn(3);
ALr(4); LiG(5); AUS(6); db(7);
onF(8); HES(9); Cnd(10);
CP2(11); dF2(12); HEt(13);
inv(14)
oUt
oA3
Relay output oA3 configuration
FAn
Pr2
nu(0); CP1(1); dEF(2); FAn(3);
ALr(4); LiG(5); AUS(6); db(7);
onF(8); HES(9); Cnd(10);
CP2(11); dF2(12); HEt (13);
inv(14)
oUt
oA4
Relay output oA4 configuration
LiG
Pr2
nu(0); CP1(1); dEF(2); FAn(3);
ALr(4); LiG(5); AUS(6); db(7);
onF(8); HES(9); Cnd(10);
CP2(11); dF2(12); HEt (13);
inv(14)
oUt
AOP
Alarm relay polarity
CL
Pr2
oP(0); CL(1)
inP
ibt
Base times for digital inputs
SEC
Pr1
SEC(0); Min(1)
inP
i1P
Digital input 1 polarity
CL
Pr1
oP(0); CL(1)
inP
i1F
Digital input 1 configuration
dor
Pr1
nu(0); dor(1); dEF(2); AUS(3);
ES(4); EAL(5); bAL(6); PAL (7);
FAn(8); HdF(9); onF(10);
LiG(11); CC(12); EMt(13)
inP
did
Digital input 1 alarm delay (base time
depends on par. ibt)
0
Pr1
sec
0 to 255 min/sec
inP
i2P
Digital input 2 polarity
CL
Pr1
OP(0); CL(1)
inP
i2F
Digital input 2 configuration
EAL
Pr1
nu(0); dor(1); dEF(2); AUS(3);
ES(4); EAL(5); bAL(6); PAL (7);
FAn(8); HdF(9); onF(10);
LiG(11); CC(12); EMt(13)
inP
d2d
Digital input 2 alarm delay (base time
depends on par. ibt)
0
Pr1
sec
0 to 255 min/sec
