Emerson Dixell XR70T User Manual

1592040000 XR20-30-60-70T EN v1.5 2021.06.22 XR20-30-60-70T 25/41
Cnt
F4H
Number of working hours for relay output
oA4 (thousands of)
Pr1
hours
read only
Cnt
F4L
Number of working hours for relay output
oA4 (units of)
Pr1
hours
read only
rtC
Hur
Hours
Pr1
read only
rtC
Min
Minutes
Pr1
read only
rtC
dAY
Day of the week
Pr1
read only
rtC
dYM
Day of the month
Pr1
read only
rtC
Mon
Month
Pr1
read only
rtC
YAr
Year
Pr1
read only
rtC
Hd1
First day of weekend
nu
Pr2
Sun(0) to SAt(6); nu(7)
rtC
Hd2
Second day of weekend
nu
Pr2
Sun(0) to SAt(6); nu(7)
rtC
iLE
Energy saving cycle start time on working
days
00:00
Pr2
hh:mm
0.0 to 23h50min
rtC
dLE
Energy saving cycle duration on working
days
00:00
Pr2
hh:mm
0.0 to 24h00min
rtC
iSE
Energy saving cycle start time on
weekends
00:00
Pr2
hh:mm
0.0 to 23h50min
rtC
dSE
Energy saving cycle duration on weekends
00:00
Pr2
hh:mm
0.0 to 24h00min
rtC
dd1
Sunday defrost
no
Pr2
n(0); Y(1)
rtC
dd2
Monday defrost
no
Pr2
n(0); Y(1)
rtC
dd3
Tuesday defrost
no
Pr2
n(0); Y(1)
rtC
dd4
Wednesday defrost
no
Pr2
n(0); Y(1)
rtC
dd5
Thursday defrost
no
Pr2
n(0); Y(1)
rtC
dd6
Friday defrost
no
Pr2
n(0); Y(1)
rtC
dd7
Saturday defrost
no
Pr2
n(0); Y(1)
rtC
Ld1
1st defrost start time
00:00
Pr2
hh:mm
0.0 to 23h50min(143); nu(144)
rtC
Ld2
2nd defrost start time
00:00
Pr2
hh:mm
0.0 to 23h50min(143); nu(144)
rtC
Ld3
3rd defrost start time
00:00
Pr2
hh:mm
0.0 to 23h50min(143); nu(144)
rtC
Ld4
4th defrost start time
00:00
Pr2
hh:mm
0.0 to 23h50min(143); nu(144)
rtC
Ld5
5th defrost start time
00:00
Pr2
hh:mm
0.0 to 23h50min(143); nu(144)
rtC
Ld6
6th defrost start time
00:00
Pr2
hh:mm
0.0 to 23h50min(143); nu(144)
E2
MAP
Current configuration
0
Pr1
C-1(0); C-2(1)
E2
LdM
Restore default factory setting
0
Pr2
n(0); Y(1)
E2
rHA
Reset for HACCP function
0
Pr2
n(0); Y(1)
CoM
Adr
Serial address
1
Pr2
1 to 247
CoM
bAU
Baudrate
9.6
Pr2
9.6(0); 19.2(1);
38.4(2); 57.6(3);
CoM
PAr
Parity control
no
Pr2
no(0); odd(1); EvE(2)
Ui
b3C
Button 3 configuration
AUS
Pr2
no(0); AUS(1); MAP(2)
Ui
b1F
Button 1 enabled in stand-by
no
Pr2
n(0); Y(1)
Ui
SCS
User interface timeout
60
Pr2
sec
1 to 255 sec
Ui
bS
Sound Level
3
Pr2
0 to 5
Ui
PSU
Password for protected level Pr2
Pr2
0 to 999
inF
dP1
Probe P1 value visualization
Pr1
read only
inF
dP2
Probe P2 value visualization
Pr1
read only
inF
dP3
Probe P3 value visualization
Pr1
read only
inF
dP4
Probe P4 value visualization
Pr1
read only
