Emerson Dixell XR70T User Manual

1592040000 XR20-30-60-70T EN v1.5 2021.06.22 XR20-30-60-70T 27/41
Prb
P4C
Probe P4 selection
ntC
Pr2
ntC; PtC; Pt1
Prb
ot
Probe P1 calibration
0
Pr1
°F
[-12.0°C to 12.0°C]
[-21.6°F to 21.6°F]
Prb
P2P
Probe P2 presence
Y
Pr1
n(0); Y(1)
Prb
oE
Probe P2 calibration
0
Pr1
°F
[-12.0°C to 12.0°C]
[-21.6°F to 21.6°F]
Prb
P3P
Probe P3 presence
no
Pr1
n(0); Y(1)
Prb
o3
Probe P3 calibration
0
Pr1
°F
[-12.0°C to 12.0°C]
[-21.6°F to 21.6°F]
Prb
P4P
Probe P4 presence
no
Pr1
n(0); Y(1)
Prb
o4
Probe P4 calibration
0
Pr1
°F
[-12.0°C to 12.0°C]
[-21.6°F to 21.6°F]
diS
CF
Temperature measurement unit: Celsius;
Fahrenheit
°F
Pr1
°C(0); °F(1)
diS
rES
Temperature resolution: decimal, integer
dE
Pr1
dE(0); in(1)
diS
Lod
Probe default displayed
P1
Pr1
P1(0); P2(1); P3(2);
P4(3); SEt(4); dtr(5)
diS
dLy
Temperature display delay (resolution 10
sec)
00:00
Pr1
mm:ss
0.0 to 20min00sec
diS
dtr
Probe visualization percentage=F(P1;P2)
(dtr=1 means VALUE=0.01*P1+0.99*P2)
99
Pr1
1 to 99
dEF
EdF
Defrost mode
rtC
Pr2
rtC(0); in(1)
dEF
tdF
Defrost type: electric heating, hot gas
EL
Pr2
EL(0); in(1)
dEF
dFP
Probe selection for defrost control
P2
Pr2
nP(0); P1(1); P2(2); P3(3); P4(4)
dEF
dtE
End defrost temperature
48.0
Pr2
°F
[-50.0°C to 50.0°C]
[-58.0°F to 122.0°F]
dEF
idF
Interval between two successive defrost
cycles
24
Pr2
ora
0 to 255 hours
dEF
MdF
Maximum length of defrost cycle
20
Pr2
min
0 to 255 min
dEF
dSd
Start defrost delay
0
Pr2
sec
0 to 255 sec
dEF
StC
Compressor stop before starting any
defrost
0
Pr2
sec
0 to 255 sec
dEF
dFd
Displaying during defrost
dEF
Pr2
rt(0); it(1); SEt(2); dEF(3); Coo(4)
dEF
dAd
Temperature display delay after any
defrost cycle
0
Pr2
min
0 to 255 min
dEF
Fdt
Draining time
1
Pr2
min
0 to 255 min
dEF
Hon
Drain heater enabled after draining time
(par. Fdt)
2
Pr2
min
0 to 255 min
dEF
dPo
Defrost cycle enebled at stat-up
no
Pr2
n(0); Y(1)
dEF
od1
Automatic defrost (at the beginning of any
energy saving mode)
no
Pr2
n(0); Y(1)
dEF
od2
Optimized defrost
no
Pr2
n(0); Y(1)
dEF
dSt
Temperature sampling time during an
optimized defrost (valid only if od2=yes)
30
Pr2
sec
1 to 255 sec
dEF
SYd
Type of synchronized defrost
nU
Pr2
nu(0); SYn(1); nSY(2)
dEF
dt1
Differential temperature for latent heating
control
0.1
Pr2
°C
0.1 to 1.0°C
dEF
ErS
Restart regulation after dripping time, when
defrost Syd = nSY
no
Pr2
n(0); Y(1)
FAn
FAP
Probe selection for evaporator fan
P2
Pr2
nP(0); P1(1); P2(2); P3(3); P4(4)
FAn
FSt
Evaporator fan stop temperature
50.0
Pr2
°F
[-50.0°C to 50.0°C]
[-58.0°F to 122.0°F]
FAn
HYF
Evaporator fan regulator differential
4.0
Pr2
°F
[0.1°C to 25.0 °C]
[0.1°F to 45.0°F]
FAn
FnC
Evaporator fan operating mode
C-n
Pr2
C-n(0); O-n(1); C-Y(2); O-Y(3)
FAn
Fnd
Evaporator fan delay after defrost cycle
1
Pr2
min
0 to 255 min
