1592040000 XR20-30-60-70T EN v1.5 2021.06.22 XR20-30-60-70T 28/41
FAn
FCt
Differential temperature for cyclic activation
of evaporator fans (o=disabled)
0
Pr2
°F
[0°C to 50°C]
[0°F to 90°F]
FAn
FSU
Evaporator fan operating mode
Std
Pr2
Std(0); FoF(1); Fon(2)
FAn
Ft
Evaporator fan controlled during defrost
no
Pr2
n(0); Y(1)
FAn
Fon
Evaporator fan ON time in normal mode
(with compressor OFF)
5
Pr2
min
0 to 255 min
FAn
FoF
Evaporator fan OFF time in normal mode
(with compressor OFF)
10
Pr2
min
0 to 255 min
FAn
Fo1
Evaporator fan ON time in energy saving
mode (with compressor OFF)
5
Pr2
min
0 to 255 min
FAn
FF1
Evaporator fan OFF time in energy saving
mode (with compressor OFF)
10
Pr2
min
0 to 255 min
FAn
Fd1
Evaporator fan delay
0
Pr2
sec
0 to 255 sec
FAn
Fd2
Evaporator fan delay after closing door
0
Pr2
sec
0 to 255 sec
FAn
FAC
Probe selection for condenser fan
P3
Pr2
nP(0); P1(1); P2(2); P3(3); P4(4)
FAn
St2
Set Point 2 regulation (for condenser fan)
50.0
Pr2
°F
[-100.0°C to 150.0°C]
[-148.0°F to 302.0°F]
FAn
Hy2
Set Point 2 differential (for condenser fan)
20.0
Pr2
°F
[0.1°C to 25.0°C]
[0.1°F to 45.0°F]
FAn
FCC
Condenser fan operating mode
C-n
Pr2
C-n(0); O-n(1); C-Y(2); O-Y(3)
FAn
Fd3
Condenser fan activation delay
0
Pr2
sec
0 to 255 sec
FAn
Fd4
Condenser fan deactivation delay
0
Pr2
sec
0 to 255 sec
AUS
ACH
Type of control for auxiliary regulator
CL
Pr2
CL(0); Ht(1)
AUS
SAA
Set point for auxiliary regulator
38.0
Pr2
°F
[-100.0°C to 150.0°C]
[-148.0°F to 302.0°F]
AUS
SHy
Auxiliary regulator differential
4.0
Pr2
°F
[0.1°C to 25.0°C]
[0.1°F to 45.0°F]
AUS
ArP
Probe selection for auxiliary regulator
nP
Pr2
nP(0); P1(1); P2(2); P3(3); P4(4)
AUS
Sdd
Auxiliary regulator disabled during any
defrost cycle
no
Pr2
n(0); Y(1)
AUS
btA
Base time for parameters Ato and AtF
SEC
Pr2
SEC; Min
AUS
Ato
Interval of time with auxiliary output ON
0
Pr2
sec
0 to 255 sec/min
AUS
AtF
Interval of time with auxiliary output OFF
0
Pr2
sec
0 to 255 sec/min
ALr
ALP
Probe selection for temperature alarms
P1
Pr1
nP(0); P1(1); P2(2); P3(3); P4(4)
ALr
ALC
Temperature alarms configuration: relative,
absolute
Ab
Pr1
rE(0); Ab(1)
ALr
ALU
High temperature alarm
302.0
Pr1
°F
°C[0.0° to 50.0° or ALL to 150.0°]
°F[0.0° to 90.0° or ALL to 302.0°]
ALr
ALL
Low temperature alarm
-100.0
Pr1
°F
°C[0.0° to 50.0° or -100.0° to ALU]
°F[0.0° to 90.0° or -148.0° to ALU]
ALr
AFH
Temperature alarm differential
4.0
Pr1
°F
[0.1°C to 25.0°C]
[0.1°F to 45.0°F]
ALr
ALd
Temperature alarm delay
0
Pr1
min
0 to 255 min
ALr
dot
Temperature alarm delay with open door
00:00
Pr1
mm:ss
0.0 to 24min00sec
ALr
dAo
Temperature alarm delay at start-up
00:00
Pr1
hh:mm
0.0 to 24h00min
ALr
AP2
Probe selection for second temperature
alarm
P2
Pr2
nP(0); P1(1); P2(2); P3(3); P4(4)
ALr
AU1
Pre-alarm threshold for second
temperature alarm (absolute value)
302.0
Pr2
°F
[-100.0°C to 150.0°C]
[-148.0°F to 302.0°F]
ALr
AH1
Second high temperature pre-alarm
differential
4.0
Pr2
°F
[0.1°C to 25.0°C]
[0.1°F to 45.0°F]
ALr
Ad1
Second high temperature pre-alarm delay
255
Pr2
min
0 to 255 min
ALr
AL2
Second low temperature alarm
-148.0
Pr2
°F
[-100.0°C to 150.0°C]
[-148.0°F to 302.0°F]
ALr
AU2
Second high temperature alarm
302.0
Pr2
°F
[-100.0°C to 150.0°C]
[-148.0°F to 302.0°F]
