DI Channel
Assignment
Definition OUT_D Values
13 Device Alarms 0x00 - No Alarm
0x01 - Cycle Count
0x02 - Time to Open
0x04 - Time to Close
0x08 - Time Board Temp Hi
0x10 - Board Temp Lo
Alarm Configuration (Optional)
Discrete Input (DI) Block may be configured for monitoring internal Device Alarms within the Control Strategy
of the Host System.
The Internal Device Alarms can be monitored using a Discrete Input (DI) Block with the Channel Parameter
assignment of 13. All alarms that are activated (checked in the Transducer Block) can be read by this single
DI block in a masked fashion. See Appendix C for Transducer Block parameter settings.
Multiple active alarms are depicted by a HEX value representing the sum of all active alarms OUT_D Val-
ues. For example, a device with a Cycle Count Alarm and a Time to Close Alarm both active would have an
OUT_D Value of 0x05.
Auxiliary Input Configuration (Optional)
The AUX Input terminal may be monitored using a Discrete Input (DI) Block with the Channel Parameter
assignment of 9.
DI Channel
Assignment
Definition OUT_D Values
9 Aux Input 0 - Aux Dry Contact Closed
1 - Aux Dry Contact Open
