Product Description
Emergency pressure relief vents are designed to
provide an emergency pressure relief opening for
storage tanks when exposed to overpressures that are
not handled by standard tank vents.
2000 Series emergency pressure relief vent (EPRV)
provides pressure relief only. 2500 Series emergency
pressure relief vent with vacuum (EPRV-V) provides
pressure and vacuum relief.
Properly-sized 2000 and 2500 Series meet the API
standard 2000 for emergency venting due to re
exposure. 2500 Series handles high capacity vacuum
ow for emergency pump-out of product. These
vents provide quick easy access for tank inspection
and maintenance.
Remote Monitoring Option
The Smart Wireless monitoring option is available with
the Enardo 2000 Series. It allows the detection of the
Open or Closed position of the emergency vent from a
remote site. Under normal conditions, the emergency
vent should be Closed. An Open indication can alert
personnel that there is a potential safety or emissions
issue that should be further investigated.
Product Identication and Marking
Hazardous Locations
Enardo Emergency Pressure Relief Vents are
available with outer housings of carbon steel, stainless
steel or aluminum as indicated in Figure 4.
The following information is stamped on the nameplate
attached to the relief valve: Model number, Flange size
and rating, Serial number, Tag number, Notied body
number, Category number, year, certicate number,
pressure setting and ow rate and vacuum setting and
ow rate.
Teon
®
and Viton
®
are marks owned by E. I. du Pont de Nemours and Company.
Figure 5. Emergency Pressure Relief Vent Model Number
2500 Series
2 5 — — — / —
Connection
Size
(16, 20 and
24
in.)
Base, Arm
and Hood
1 = Carbon Steel
2 = 304 Stainless
Steel
3 = 316 Stainless
Steel
4 = Exotic
Disk and
Seal Support
1 = Aluminum
2 = 316 Stainless
Steel
3 = Exotic
Vacuum Pallet
and Seat
1 = Polyphenylene
Sulde
2 = 316 Stainless
Steel
3 = Exotic
Gasket
Seal
T = Teon
®
N = Buna-N
V = Viton
®
X = Special
Pressure
Settings
n = in. w.c.
z = oz./sq. in.
4.0 to 16.0 oz./sq. in.
(0.5 oz./sq. in.
increments)
7.0 to 27.0 in. w.c.
(0.5 in. w.c.
increments)
17.4 to 67.2 mbar
(2.2 mbar
increments)
Vacuum
Settings
0.5,
0.75,
1.0 or
2.0 oz./sq.in.
Options
1 = Special
Coating
2 = Optional
Hardware
3 = Other
Series
Bolt
Pattern
1 = ANSI
2 = API
2000 Series
2 0 — — — —
Connection
Size
(4, 8, 12, 16,
18, 20 and
24
in.)
Base and
Arm
2 = Carbon
Steel
3 = 304 Stainless
Steel
4 = 316 Stainless
Steel
5 = Exotic
Disk Cover
1 = Aluminum
3 = 304 Stainless
Steel
4 = 316 Stainelss
Steel
5 = Exotic
Gasket
T = Teon
®
N = Buna-N
V = Viton
®
X = Special
Pressure
Settings
n = in. w.c.
z = oz./sq. in.
2.0. to 32.0 oz./sq. in.
(0.5 oz./sq. in.
increments)
3.5 to 55.0 in. w.c.
(1.0 in. w.c.
increments)
8.6 to 138 mbar
(2.2 mbar increments)
Options
1 = Special
Coating
2 = Optional
Hardware
3 = Other
4 = Smart
Wireless
Monitoring
Series
Bolt
Pattern
1 = ANSI
2 = API
