1-1-1 T5553SP
SPECIFICATIONS
*ˆMode---------SP mode unless otherwise specified
*Test input terminal
<Except Tuner>-------------Video input (1Vp-p)
Audio input (-10dB)
<Tuner>-----------------------Ant. input (80dBµV) Video: 87.5%
Audio: 25kHz dev (1kHz Sin)
<DEFLECTION>
<VIDEO & CHROMA>
<VCR>
<TUNER>
Description Condition Unit Nominal Limit
1. Over Scan — % 90 ±5
2. Linearity Horizontal % — 15
Vertical % — 10
3. High Voltage — kV 22 —
Description Condition Unit Nominal Limit
1. Misconvergence Center m/m — 0.3
Corner m/m — 1.5
Side m/m — 1.2
2. Tint Control Range — deg ±30 —
3. Contrast Control Range — dB 12 8
4. Brightness APL 100% ft-L 55 40
5. Color Temperature — K 9200 —
Description Condition Unit Nominal Limit
1. Horizontal Resolution (R/P) Line 230 200
2. Jitter (Low) (R/P) µS 0.05 0.2
3. S/N Chroma AM(SP) (R/P) dB 38 33
PM(SP) (R/P) dB 36 33
4. Wow & Flutter (RMS) (R/P) % 0.25 0.5
Description Condition Unit Nominal Limit
1. Video S/N — dB 45 40
2. Audio S/N (W/LPF) — dB 43 40
