49
EN
CRT 19 inch in-line gun,
90˚ deflection tube
Television system : NTSC-M
Closed caption system :§15.119/FCC
Video Heads : Rotary four-head
Tape width : 1/2 inch
Tape speed
SP : 33.40mm/sec.
LP : 16.67mm/sec.
SLP : 11.12mm/sec.
Tuner channel
TV VHF Low : #2~#6
TV VHF High : #7~#13
TV UHF : #14~#69
CATV
VHF : 5A
MID band : A5~A1, A~I
SUPER band : J~W
HYPER band : W+1~W+84
Product type: DVD Player
Discs: DVD video, Audio CD
Output signal format: NTSC color
Designs and specifications are subject to change without notice.
If there is a discrepancy between languages, the default language will be English.
TV/VCR
DVD
GENERAL SPECIFICATIONS ELECTRICAL SPECIFICATIONS
Sound output: 2 speakers, 1W, 8 ohm
OTHER SPECIFICATIONS
Terminals
Antenna input: VHF/UHF/CATV
75 ohm unbalanced (F-type)
Video input: RCA connector [ 1
Audio L/R input: RCA connector [ 2
Headphone: 1/8” stereo (3.5 mm)
Coaxial digital
audio output: One pin jack,
500m Vpp (75 ohm)
Remote control: Digital encoded
infrared light system
Operating
temperature: 5˚C to 40˚C
(41˚F~104˚F)
Power requirements: AC 120V, 60Hz
Power consumption
(Maximum): 90W
Picture tube: 19"
Dimensions: H:19-11/16" (500mm)
W:21-7/8" (556mm)
D:18-3/4" (477mm)
Weight: 45.2 lbs. (20.5kg)
SPECIFICATIONS
