Emerson EWF2006 Service Manual

1-1 L3314SP
SPECIFICATIONS
< TUNER >
ANT. Input ---------------------- 75 ohm Unbal., F type
Reference Level--------------- 20 Vp-p (CRT Green Cathode)
Test Input Signal -------------- 400 Hz 30% modulation
< DEFLECTION >
< VIDEO & CHROMA >
< AUDIO >
All items are measured across 8 Ω load at speaker output terminal.
Note: Nominal specifications represent the design specifications. All units should be able to approximate these.
Some will exceed and some may drop slightly below these specifications. Limit specifications represent
the absolute worst condition that still might be considered acceptable. In no case should a unit fail to meet
limit specifications.
Description Condition Unit Nominal Limit
1. Intermediate Freq.
Sound
MHz
MHz
45.75
41.25
---
---
2. Peak Picture Sens
VHF
CATV
UHF
dBµV
dBµV
dBµV
15
15
15
30
30
30
3. AFT Pull In Range (10 mV input) --- MHz ±2.0 ±0.7
Description Condition Unit Nominal Limit
1. Deflection Freq.
Horizontal
Vertical
kHz
Hz
15.734
60
---
---
2. Linearity
Horizontal
Ver tical
%
%
---
---
±15
±10
3. Over Scan --- % 10 ---
4. High Voltage --- kV 29 ---
Description Condition Unit Nominal Limit
1. Misconvergence
Center
Side
Corner
mm
mm
mm
---
---
---
0.4
1.5
2.1
2. Brightness APL 100% Ft-L 30 25
3. Color Temperature --- °K 9200 ---
4. Resolution
Horizontal
Ver tical
Line
Line
250
300
---
---
Description Condition Unit Nominal Limit
1. Audio Output Power 10% THD W 1 0.8
2. Audio Distortion (w/LPF) 500 mW % 2 7
3. Audio Freq. Response -3 dB Hz 70 ~ 11 k ---
