Page #31 background imageLoading...
Page #31 background image
Q501
Base
WF3
Q501
Collector
WF15
Q503
Base
WF5
Q503
Collector
WF13
Q502
Base
WF4
Q502
Collector
WF14
TP501
GND
TP1502
BLUE
7-11
BL6118F01011-2
7-12
CRT CBA Top View
CRT CBA Bottom View
CRT CBA
Ref No. Position
Q501
B-2
Q502
B-2
Q503
C-2
TP501 B-3
TP502 A-2
CN501
A-2
WH301B B-1
WH501B B-1
TRANSISTORS
TEST POINTS
CONNECTORS
