67C Series
11
SOFT SEAT
(KEY 15)
VALVE CARTRIDGE
(KEY 10)
VALVE SPRING
(KEY 12)
VALVE PLUG
(KEY 11)
O-RING
(KEY 14)
VALVE RETAINER
(KEY 13)
B2695
Figure 12. Valve Cartridge Assembly
Figure 10. Diaphragm Assembly (Key 16)
Figure 11. Optional Closing Cap
(Only Available with the 1/4-inch Spring Case Vent)
B2698
Figure 13. Spacer Diameter and Assembly
(For Installing in an Existing Installation
if the Mounting Bolts are too Long)
0.50
(12.7)
0.18
(4,57)
0.32
(8,12)
SPACER OUTER DIAMETER SPACER WIDTH AND
INNER DIAMETER
ID
OD
B2697
RETAINING RING
DIAPHRAGM
PLATE
PUSHER POST
(WITHOUT RELIEF)
PUSHER POST
(WITH RELIEF)
DIAPHRAGM
B2696
LOWER SPRING
SEAT
SPACER
