Emerson Fisher 8532 User Manual

Instruction Manual
D101550X012
8532 Valve
June 2017
3
Table 2. Material Temperature Ratings
COMPONENT AND MATERIAL OF CONSTRUCTION
(1)
TEMPERATURE RANGE
_C _F
Valve Body
(2)
Carbon Steel (WCC or SA 516-70)
(7)
CF8M (316 SST)
CF8M/CF10M (316/316H)
(3)
Dual-Certified
-29 to 427
-198 to 538
over 538 to 816
-20 to 800
-325 to 1000
over 1000 to 1500
Disk
CF8M (316 SST)
CF8M/CF10M (316/316H)
(3)
Dual-Certified
-198 to 538
over 538 to 816
-325 to 1000
over 1000 to 1500
Disk Coating
Chromium Carbide
Chrome Plating
Chromium Coating
-198 to 916
-254 to 316
-254 to 593
-325 to 1500
-425 to 600
-425 to 1100
Shaft
S20910
S17400 (17-4 pH 1025)
N07718
N07750
N05500
-198 to 538
-73 to 427
-254 to 704
over 593 to 816
-198 to 482
-325 to 1000
-100 to 800
-425 to 1300
over 1100 to 1500
-325 to 900
Bearings
(6)
PEEK (standard)
S31600
(4)
R30006 (Alloy 6)
Bronze
-73 to 260
-198 to 816
-198 to 816
-254 to 302
-100 to 500
-325 to 1500
-325 to 1500
-425 to 575
Packing
PTFE Packing and PTFE ENVIRO-SEAL Packing
Graphite packing
Graphite packing with oxidizing media
Graphite ENVIRO-SEAL Packing
-148 to 232
-198 to 916
-198 to 538
-148 to 315
-325 to 450
-325 to 1500
-325 to 1000
-325 to 600
Seal Ring and
Backup Ring
PTFE Seal Ring
Nitrile Backup O-Ring
Chloroprene Backup O-Ring
EPR Backup O-Ring
Fluorocarbon Backup O-Ring
PTFE Backup O-Ring
-29 to 93
-43 to 149
-54 to 182
-29 to 204
-73 to 204
-20 to 200
-45 to 300
-65 to 360
-20 to 400
-100 to 400
UHMWPE
(5)
Seal Ring (CL150 Only)
EPR Backup O-Ring
Fluorocarbon Backup O-Ring
-54 to 93
-29 to 93
-65 to 200
-20 to 200
Phoenix III and/or Fire Tested Construction
S31600 and PTFE Seal Ring with Nitrile Backup O-Ring
Chloroprene Backup O-Ring
EPR Backup O-Ring
Fluorocarbon Backup O-Ring
-40 to 149
-54 to 149
-62 to 204
-40 to 232
-40 to 300
-65 to 300
-80 to 400
-100 to 200
Seal Ring
NOVEX S31600 Seal
(4)
Ring (CL150)
NOVEX S31600 Seal
(4)
Ring (CL300)
NOVEX S21800 Seal
(4)
Ring (CL300)
-29 to 538
-29 to 816
-29 to 816
-20 to 1000
-20 to 1500
-40 to 1500
Cryogenic Seal Ring Contact your Emerson Sales office or Local Business Partner
1. NACE trim constructions are available; consult your Emerson sales office.
2. Special gasket retainer bolts are required for over 482_C (900_F)
3. Special retaining ring screws for lugged valves over 538_C (1000_F)
4. For a complete material description, contact your Emerson sales office.
5. UHMWPE stands for ultra high molecular weight polyethylene.
6. Special thrust bearings are required for high temp. applications over 343_C (650_F) (with 6- and 12-inch shaft extensions). Constructions with carbon steel valves and SST disks may require
special thrust bearings at temperatures less than 343_C (650_F).
7. Cast or wrought /plate grades used interchangeably, depending upon availability - unless requested by customer.
