Instruction Manual
D102175X012
EZ-C, ET-C, and EWT-C Valves
July 2017
21
Key 7* Fisher EZ‐C Valve Stem, S20910 (Use W/Group 1 Actuators)
VALVE SIZE, NPS
STEM DIAMETER
9.5 mm (3/8 Inch) 12.7 mm (1/2 Inch) 12.7 x 9.5 mm (1/2 x 3/8 Inch) 19.1 mm (3/4 Inch)
1 and 1-1/2 10A8823XM72 10A8840XBC2 11A2318X622 ‐ ‐ ‐
2 ‐ ‐ ‐ 10A8840XBD2 11A2318X632 10B9265XBC2
3 ‐ ‐ ‐ 10A8840XBE2 ‐ ‐ ‐ 10A9265XBD2
4 ‐ ‐ ‐ 1U2307X0012 ‐ ‐ ‐ 10A9265XBE2
Key 8* Fisher EZ‐C Pin, S31600
VALVE SIZE, NPS VALVE PLUG STYLE
VALVE STEM CONNECTION
PART NUMBER
mm Inch
1 and 1-1/2
Micro‐Form, Linear, Equal Percentage and Quick
Opening
9.5
12.7
3/8
1/2
1B599335072
1D5423X00B2
2
Linear, Equal Percentage and Quick Opening (full
capacity)
12.7
19.1
1/2
3/4
1B599835072
1B813635072
Micro‐Form, Linear, Equal Percentage and Quick
Opening (restricted capacity)
9.5
12.7
3/8
1/2
1B599335072
1D5423X00B2
3 All
12.7
19.1
1/2
3/4
1B599835072
1B813635072
4
Full Capacity
12.7
19.1
1/2
3/4
1B599835072
1B813635072
Restricted Capacity
12.7
19.1
1/2
3/4
1B599335072
1F723635072
Key 9* Fisher EZ‐C Valve Seat Ring, S31600
VALVE
SIZE,
NPS
PORT DIAMETER
6.4 mm
(0.25 Inch)
9.5 mm
(0.375 Inch)
12.7 mm
(0.5 Inch)
19.1 mm
(0.75 Inch)
25.1 mm
(1 Inch)
38.1 mm
(1.5 Inch)
50.8 mm
(2 Inch)
76.2 mm
(3 Inch)
101.6 mm
(4 Inch)
1 24B7585X012 24B8298X012 24B8299X012 24B8300X012 24B8301X012 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
1-1/2 24B6344X012 24B7586X012 24B7213X012 24B7214X012 24B7215X012 24B7216X012 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
2 24B8555X012 24B8556X012 24B8557X012 24B8558X012 24B8559X012 ‐ ‐ ‐ 24B8560X012 ‐ ‐ ‐ ‐ ‐ ‐
3 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ 24B8561X012 24B8562X012 ‐ ‐ ‐
4 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ 24B8510X012 ‐ ‐ ‐ 24B8563X012
*Recommended spare parts
