EZ-C, ET-C, and EWT-C Valves
July 2017
20
Key 2* Fisher EZ‐C Equal Percentage (Including Micro‐Form), Linear, and Quick‐Opening Valve Plugs
VALVE SIZE, NPS VALVE PLUG STYLE
PORT DIAMETER
VALVE STEM
CONNECTION
VALVE PLUG MATERIAL
mm Inch mm Inch
S31600 w/CoCr‐A (alloy 6)
Seat
S31600 w/CoCr‐A
Seat and Guide
1, 1-1/2 and 2
Micro‐Form
6.4 0.25
9.5 3/8
15A6663X012 15A6664X012
9.5 0.375 16A5713X012 16A5711X012
12.7 0.5 15A6659X012 15A6660X012
19.1 0.75 16A3337X012 16A3339X012
9.5 0.375
12.7 1/2
16A5714X012 16A5712X012
12.7 0.5 15A6661X012 15A6662X012
19.1 0.75 16A3338X012 16A3340X012
Quick Opening
25.4 1
9.5 3/8 15A6516X012 15A6517X012
12.7 1/2 15A6518X012 15A6519X012
Linear
9.5 3/8 15A6614X012 15A6615X012
12.7 1/2 15A6616X012 15A6617X012
Equal Percentage
9.5 3/8 15A6634X012 15A6635X012
12.7 1/2 15A6636X012 15A6637X012
1-1/2
Quick Opening
38.1 1.5
9.5 3/8 15A6520X012 15A6521X012
12.7 1/2 15A6522X012 15A6523X012
Linear
9.5 3/8 15A6618X012 15A6619X012
12.7 1/2 15A6620X012 15A6621X012
Equal Percentage
9.5 3/8 15A6638X012 15A6639X012
12.7 1/2 15A6640X012 15A6641X012
2, 3, 4
Quick Opening
50.8 2
12.7 1/2 15A6524X012 15A6525X012
19.1 3/4 15A6526X012 15A6527X012
Linear
12.7 1/2 15A6622X012 15A6623X012
19.1 3/4 15A6624X012 15A6625X012
Equal Percentage
12.7 1/2 15A6642X012 15A6643X012
19.1 3/4 15A6644X012 15A6645X012
3
Quick Opening
76.2 3
12.7 1/2 15A6528X012 15A6529X012
19.1 3/4 15A6530X012 15A6531X012
Linear
12.7 1/2 15A6626X012 15A6627X012
19.1 3/4 15A6628X012 15A6629X012
Equal Percentage
12.7 1/2 15A6646X012 15A6647X012
19.1 3/4 15A6648X012 15A6649X012
4
Quick Opening
101.6 4
12.7 1/2 15A6532X012 15A6533X012
19.1 3/4 15A6534X012 15A6535X012
Linear
12.7 1/2 15A6630X012 15A6631X012
19.1 3/4 15A6632X012 15A6633X012
Equal Percentage
12.7 1/2 15A6650X012 15A6651X012
19.1 3/4 15A6652X012 15A6653X012
Key 3*, 26* Fisher EZ‐C Seat Ring Retainer and Bushing Assembly
VALVE SIZE, NPS PART NUMBER
1 25A6683X072
1-1/2 25A6685X082
2
Full Port 25A6687X112
Restricted Port 25A6687X132
3 25A6689X132
4
Full Port 35A6691X082
Restricted Port - - -
*Recommended spare parts
