Emerson Fisher GX

Instruction Manual
D103175X012
GX Valve and Actuator
April 2011
40
Key 3 Valve Plug/Stem and Key 2 Seat Ring (Plain Bonnet, LCC, WCC/1.0619 and CF3M/1.4409 Valve Body Material)
VALVE
SIZE
PORT
SIZE
TRAVEL
PLUG STYLE
VALVE
PLUG
MATERIAL
STEM
MATERIAL
SEAT RING
MATERIAL
TRIM STYLE
VALVE
PLUG/STEM
PART NUMBER
SEAT RING
PART NUMBER
mm mm
DN15
(NPS
1/2)
4.8 20 Unbalanced R31233
S31603
CF3M Micro‐Flow Flat
1_8' GE04253X032
(1)
2_15' GE04255X032
GE04252X012
4_39' GE04256X032
9_30' GE13780X012
S31603/
CoCr‐A Seat
Micro‐Flow Flat
1_8' GE04253X112
(1)
2_15' GE04255X032
GE04252X052
4_39' GE04256X032
9_30' GE13780X012
N06022 CW2M Micro‐Flow Flat
1_8' GE04253X072
(1)
2_15' GE04255X072
GE04252X042
4_39' GE04256X072
9_30' GE13780X032
9.5 20
Unbalanced
(Standard)
S31603 S31603 CF3M
Equal Percentage GE03891X012
GE00051X012
Linear GE03893X012
S31603/
CoCr‐A Seat
S20910 SST
CF3M/
CoCr‐A Seat
Equal Percentage GE03891X022
GE00051X062
Linear GE03893X022
N06022 N06022 CW2M
Equal Percentage GE03891X052
GE00051X052
Linear GE03893X052
Unbalanced
(Reduced
Capacity)
S31603 S31603 CF3M Equal Percentage GE08919X012 GE00051X012
S31603/
CoCr‐A Seat
S20910 SST
CF3M/
CoCr‐A Seat
Equal Percentage GE08919X022 GE00051X062
N06022 N06022 CW2M Equal Percentage GE08919X052 GE00051X052
DN20
(NPS
3/4)
4.8 20 Unbalanced R31233
S31603
CF3M Micro‐Flow Flat
1_8' GE04253X032
(1)
2_15' GE04255X032
GE04252X012
4_39' GE04256X032
9_30' GE13780X012
S31603/
CoCr‐A Seat
Micro‐Flow Flat
1_8' GE04253X112
(1)
2_15' GE04255X032
GE04252X052
4_39' GE04256X032
9_30' GE13780X012
N06022 CW2M Micro‐Flow Flat
1_8' GE04253X072
(1)
2_15' GE04255X072
GE04252X042
4_39' GE04256X072
9_30' GE13780X032
9.5 20
Unbalanced
(Standard)
S31603 S31603 CF3M
Equal Percentage GE03891X012
GE00051X012
Linear GE03893X012
S31603/
CoCr‐A Seat
S20910 SST
CF3M/
CoCr‐A Seat
Equal Percentage GE03891X022
GE00051X062
Linear GE03893X022
N06022 N06022 CW2M
Equal Percentage GE03891X052
GE00051X052
Linear GE03893X052
Unbalanced
(Reduced
Capacity)
S31603 S31603 CF3M Equal Percentage GE08919X012 GE00051X012
S31603/
CoCr‐A Seat
S20910 SST
CF3M/
CoCr‐A Seat
Equal Percentage GE08919X022 GE00051X062
N06022 N06022 CW2M Equal Percentage GE08919X052 GE00051X052
14 20 Unbalanced
S31603 S31603 CF3M
Equal Percentage GE03890X012
GE00049X012
Linear GE03892X012
S31603/
CoCr‐A Seat
S20910 SST
CF3M/
CoCr‐A Seat
Equal Percentage GE03890X022
GE00049X062
Linear GE03892X022
N06022 N06022 CW2M
Equal Percentage GE03890X052
GE00049X052
Linear GE03892X052
1. The seat ring is included in the Valve Plug / Stem Part Number.
