Instruction Manual
D103175X012
GX Valve and Actuator
April 2011
39
Parts List
Note
For part numbers not shown, contact your Emerson Process
Management sales office.
Key Description Part Number
1 Valve Body
2* Seat Ring see following table
3* Valve Plug/Stem see following table
4 Bonnet
5* Body/Bonnet Gasket, graphite laminate see gasket kits table
6 Body/Bonnet Bolting (4 req'd)
7 Body/Bonnet Nut (4 req'd)
8 Actuator Yoke
9 Upper Diaphragm Casing
10* Diaphragm
11 Diaphragm Plate
12 Actuator Springs
13 Actuator Spacer
14 Cap Screw
15 Washer
16 Cap Screw, long
Size 225 Actuator (2 req'd)
Size 750 Actuator (2 req'd)
Size 1200 Actuator (4 req'd)
17 Cap Screw, short
Size 225 Actuator (4 req'd)
Size 750 Actuator (8 req'd)
Size 1200 Actuator (12 req'd)
18 Hex Nut
Size 225 Actuator (6 req'd)
Size 750 Actuator (10 req'd)
Size 1200 Actuator (16 req'd)
19* Actuator Rod Bushing
20* Actuator Rod Seal
21 Vent Cap
22 Actuator Rod
23 Stem Connector Nut Half
24 Stem Connector Bolt Half
25 Cap Screw (2 req'd)
26 Travel Indicator
27 Stem Adjustor Nut
28 Locknut
29 Packing Follower
30 Packing Spacer
31 Packing Box Ring
32* Anti‐Extrusion Washer (2 req'd)
33* PTFE Packing Set
34 Belleville Spring (3 req'd)
Key Description
35 Nameplate
36 Warning Tag
37* Seal Ring
38* Backup Ring
39 Extension Bonnet
40 Stem Extension
41 Extension Bonnet Lower Bushing
42* Graphite ULF Packing Ring (2 req'd)
43* Packing Ring (2 req'd)
44* Packing Washer (3 req'd)
45 Yoke/Extension Bonnet Bolting (4 req'd)
46 Yoke/Extension Bonnet Nut (4 req'd)
47* Extension Bonnet Gasket
48* Insert (req'd for assembly of valve stem to extension stem)
49* Bellows/Stem Assembly
50* Bellows Gasket
51 Bellows Nut
52 Pipe Plug
53 Handjack Body
54 Lever
55 Operating Nut
56 Drive Screw
57 Pivot Washer
58 Grooved Pin
59 Bearing
60 Pivot Pin
61 Bushing
62 Retainer Ring
63 Spacer
64 Cap Screw
65 Hex Nut
66 Lock Screw
67 Hex Nut
68 Stud
69 Hex Nut
70 Lubricant, Lithium Grease
71 Lubricant, Anti‐Seize
72 Cap Plug
73 Warning Tag
74 Travel Indicator Scale
75 Zerk Fitting
76 Handwheel
77 Locknut
78 Pipe Plug
79 Anti‐seize sealant
80 Lubricant, silicone sealant
81 Pipe Plug
82 Inner Actuator Spring
84 Guide Sleeve or Cage
98 Low Temp Bushing
99 Cavitrol III cage
100 Piston Ring
*Recommended spare parts
