Key 3 Valve Plug/Stem and Key 2 Seat Ring (Plain Bonnet, CF3 Valve Body Material)
VALVE
SIZE
PORT
SIZE
TRAVEL
PLUG STYLE
VALVE
PLUG
MATERIAL
STEM
MATERIAL
SEAT RING
MATERIAL
TRIM STYLE
VALVE
PLUG/STEM
PART NUMBER
SEAT RING
PART NUMBER
mm mm
DN80
(NPS 3)
36 20 Unbalanced
CF3 S31803 CF3
Equal Percentage GE00097X042
GE12612X062
Linear GE00098X042
CF3 S31803
CF3/
PTFE Seat
Equal Percentage GE00097X042
GE12745X222
Linear GE00098X042
46 20 Unbalanced
CF3 S31803 CF3
Equal Percentage GE00095X042
GE12611X062
Linear GE00096X042
CF3 S31803
CF3/
PTFE Seat
Equal Percentage GE00095X042
GE12745X232
Linear GE00096X042
70
40 Unbalanced
CF3 S31803 CF3
Equal Percentage GE00093X042
GE12610X062
Linear GE00094X042
CF3 S31803
CF3/
PTFE Seat
Equal Percentage GE00093X042
GE12745X242
Linear GE00094X042
20 Balanced S30403 S31803 CF3
Equal Percentage GE00087X042
GE12610X062
Linear GE00088X042
DN100
(NPS 4)
46 20 Unbalanced
CF3 S31803 CF3
Equal Percentage GE01114X042
GE12615X062
Linear GE01115X042
CF3 S31803
CF3/
PTFE Seat
Equal Percentage GE01114X042
GE12745X252
Linear GE01115X042
70 40 Unbalanced
CF3 S31803 CF3
Equal Percentage GE01112X042
GE12614X062
Linear GE01113X042
CF3 S31803
CF3/
PTFE Seat
Equal Percentage GE01112X042
GE12745X262
Linear GE01113X042
90
40 Unbalanced
CF3 S31803 CF3
Equal Percentage GE00091X042
GE12613X062
Linear GE00092X042
CF3 S31803
CF3/
PTFE Seat
Equal Percentage GE00091X042
GE12745X272
Linear GE00092X042
20
Balanced
(Standard)
S30403 S31803 CF3
Equal Percentage GE00099X042
GE12613X062
Linear GE00100X042
Balanced
(Reduced
Capacity)
S30403 S31803 CF3
Equal Percentage GE00089X042
Linear GE00090X042
