Emerson insinkerator W152 User Manual

1
1
2
24
3
HIGH LIMIT
SINGLE THROW
THERMOSTAT
ELEMENT
BLACK
(HOT)
WHITE
(NEUTRAL)
3 WIRE POWER CORD
110-120 VAC
IMPORTANT:
WHITE SIDE OF CORD
TO THIS TERMINAL
COLD INLET
(1/2'' NPT FEMALE)
10-1/2''
20-5/8'' (W154)
13-1/2'' (W152)
10-1/4''
3-1/8''
1-1/2''
T & P VALVE BOSS
3/4'' NPT FEMALE
HOT OUTLET
(1/2'' NPT FEMALE)
WIRING DIAGRAM
HEATER DIMENSIONS
15
Personal Injury: The cord of this
heater must be used with a properly
grounded outlet to insure proper
safety and operation. Do not use a 3 prong to a 2 prong
adapter. Water heater is not to be hard wired.

Emerson insinkerator W152 Specifications

General

Brand	Emerson
Model	insinkerator W152
Category	Water Heater
Language	English
