Emerson insinkerator W152 - Page 2

W152
ON-OFF
SWITCH
DRAIN SCREW
ACCESS SCREW
ACCESS COVER
HOT WATER OUTLET
(½" NPT FEMALE)
3½' CORD
T & P VALVE
(PRE-INSTALLED ON SOME MODELS)
COLD WATER INLET VALVE
(NOT SUPPLIED)
COLD WATER INLET
(½" NPT FEMALE)
W154
ON-OFF
SWITCH
T & P VALVE
(PRE-INSTALLED ON SOME MODELS)
COLD WATER INLET VALVE
(NOT SUPPLIED)
COLD WATER INLET
(½" NPT FEMALE)
DRAIN SCREW
ACCESS SCREW
ACCESS SCREW
ACCESS COVER
HOT WATER OUTLET
(½" NPT FEMALE)
3½' CORD
2
