20080213 13-1 A8AF1EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DIGITAL MAIN CBA UNIT
MPS CBA
POWER SUPPLY CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT 1ESA16685
Ref. No. Description Part No.
MPS CBA
Consists of the following
1ESA16506
POWER SUPPLY CBA(MPS-1)
FUNCTION CBA(MPS-3)
IR SENSOR CBA(MPS-4)
JUNCTION-A CBA(MPS-5)
----------
----------
----------
----------
Ref. No. Description Part No.
POWER SUPPLY CBA(MPS-1)
Consists of the following:
----------
CAPACITORS
C1 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C2 CHIP CERAMIC CAP.(1608) CH J 22pF/50V CHD1JJ3CH220
C3 CHIP CERAMIC CAP.(1608) CH J 22pF/50V CHD1JJ3CH220
C4 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C5 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C6 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C8 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C9 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C10 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C11 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C12 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C13 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C14 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C15 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C17 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C18 ELECTROLYTIC CAP. 330µF/10V M CE1AMASDL331
C19 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C21 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C22 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C23 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C24 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C501 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C601# ELECTROLYTIC CAPACITOR 270µF/200V CA2D271DYG05
C602 CERAMIC CAP. HR 470pF/2KV CCD3DKA0R471
C603 CAP CERAMIC (AX) 560pF/50V/B/K CA1J561TU061
C604 POLYESTER FILM CAP. (PB FREE) 0.047µF/
100V J
CA2A473DT018
C605 POLYESTER FILM CAP. (PB FREE) 0.0022µF/
100V J
CA2A222DT018
C606 POLYESTER FILM CAP. (PB FREE) 0.1µF/100V
J
CA2A104DT018
C607# SAFTY CAP. 2200pF/250V KX CA2E222MR101
C608 SAFTY CAP. 2200pF/250V KX CA2E222MR101
C633 ELECTROLYTIC CAP. 470µF/25V M CE1EMASDL471
C634 ELECTROLYTIC CAP 3300µF/10V CE1AMZNDL332
C635 POLYESTER FILM CAP. (PB FREE) 0.0022µF/
100V J
CA2A222DT018
C636 CERAMIC CAP. R K 1500pF/2KV(HR) CCD3DKA0R152
C638 ELECTROLYTIC CAP. 1000µF/35V M CE1GMZADL102
C639 ELECTROLYTIC CAP. 220µF/50V M CE1JMASDL221
C640 CAP CERAMIC (AX) 0.01µF/50V/B/K CA1J103TU061
C642 CAP ELE STD-85 4700µF 6.3V SL CE0KMZNDL472
C643 ELECTROLYTIC CAP. 1000µF/10V M CE1AMASDL102
C644 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C647 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C650 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C651 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C652 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C653 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C654 ELECTROLYTIC CAP. 1000µF/10V M CE1AMASDL102
C655 ELECTROLYTIC CAP. 1000µF/10V M CE1AMASDL102
C656 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C657 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C658 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C659 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C660 ELECTROLYTIC CAP. 22µF/50V M CE1JMASDL220
C661 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C662 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C663 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C664 ELECTROLYTIC CAP 3300µF/6.3V M CE0KMZNDL332
C666 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C668 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C669 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C670 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C671 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C701 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C702 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C703 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C704 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C705 CHIP CERAMIC CAP. B K 470pF/50V CHD1JK30B471
C706 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C707 CHIP CERAMIC CAP. B K 470pF/50V CHD1JK30B471
C708 CHIP CERAMIC CAP.(1608) CH J 68pF/50V CHD1JJ3CH680
C709 CHIP CERAMIC CAP.(1608) CH J 68pF/50V CHD1JJ3CH680
C712 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C713 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C714 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C801 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C802 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C803 ELECTROLYTIC CAP. 1000µF/25V M CE1EMZNDL102
C804 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C805 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C806 ELECTROLYTIC CAP. 2.2µF/50V M CE1JMASDL2R2
Ref. No. Description Part No.
