20080213 13-2 A8AF1EL
C807 CHIP CERAMIC CAP.(1608) B K 0.47µF/16V CHD1CK30B474
C808 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C809 CHIP CERAMIC CAP.(1608) B K 0.47µF/16V CHD1CK30B474
C810 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C811 CHIP CERAMIC CAP.(1608) B K 0.47µF/10V CHD1AK30B474
C812 CHIP CERAMIC CAP.(1608) B K 0.47µF/10V CHD1AK30B474
C813 CHIP CERAMIC CAP.(1608) B K 0.47µF/10V CHD1AK30B474
C814 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C815 ELECTROLYTIC CAP. 2.2µF/50V M CE1JMASDL2R2
C816 CHIP CERAMIC CAP.(1608) B K 0.47µF/16V CHD1CK30B474
C817 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C818 CHIP CERAMIC CAP.(1608) B K 0.47µF/16V CHD1CK30B474
C819 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C820 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C821 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C824 CHIP CERAMIC CAP.(1608) B K 0.47µF/10V CHD1AK30B474
C825 CHIP CERAMIC CAP.(1608) B K 0.47µF/10V CHD1AK30B474
C826 CHIP CERAMIC CAP.(1608) B K 3300pF/50V CHD1JK30B332
C827 CHIP CERAMIC CAP.(1608) B K 3300pF/50V CHD1JK30B332
C7001 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C7002 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C7003 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C7004 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7005 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7006 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7007 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7008 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C7009 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C7010 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C7012 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C7013 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C7101 ELECTROLYTIC CAP. 220µF/10V M CE1AMASDL221
C7102 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C7109 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7110 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7111 ELECTROLYTIC CAP. 220µF/10V M CE1AMASDL221
C7201 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C7202 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
C7203 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C7204 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C7301 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7302 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7303 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C7304 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C7305 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C7306 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C7307 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7308 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7401 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7402 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7602 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7605 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7608 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7611 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7615 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7618 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7621 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7624 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C7701 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7702 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7705 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7706 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7709 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
Ref. No. Description Part No.
C7710 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7714 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7715 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C7718 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7719 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7723 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7724 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C7729 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7730 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7733 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7734 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7738 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7739 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7743 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7744 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7747 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7748 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7751 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7752 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7801 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C7802 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
CONNECTORS
CN102 242 SERIES CONNECTOR 224202106W1 J322C06TG001
CN301 TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN302 TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN303 TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN501 242 SERIES CONNECTOR 224202104W1 J322C04TG001
CN601 WIRE ASSEMBLY 004 2PIN / 100MM / AWG18 WX1A8AF0-004
CN801 PH CONNECTOR TOP 2P B2B-PH-K-S
(LF)(SN)
J3PHC02JG029
CN802 PH CONNECTOR TOP 2P B2B-PH-K-S
(LF)(SN)
J3PHC02JG029
DIODES
D2 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D3 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D502 ZENER DIODE MTZJT-775.6A QDTA0MTZJ5R6
D503 DIODE FR104-B NDLZ000FR104
D504 ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D505 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D506 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D507 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D508 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D509 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D510 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D511 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D513 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D514 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D602# ZENER DIODE MTZJT-7739B QDTB00MTZJ39
D603 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D604# ZENER DIODE MTZJT-7727B QDTB00MTZJ27
D606 ZENER DIODE MTZJT-774.3B QDTB0MTZJ4R3
D607 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D631 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D632 SCHOTTKY BARRIER DIODE ERB81-004 AERB81004***
D633 DIODE FR154 NDLZ000FR154
D634 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
D635 ZENER DIODE MTZJT-7720B QDTB00MTZJ20
D636 DIODE FR154 NDLZ000FR154
D637 DIODE FR154 NDLZ000FR154
D638 SCHOTTKY BARRIER DIODE ERC84-009 QDLZERC84009
D639 SCHOTTKY BARRIER DIODE ERC84-009 QDLZERC84009
D640 SCHOTTKY BARRIER DIODE SB340 NDQZ000SB340
D641 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
Ref. No. Description Part No.
