20080213 13-3 A8AF1EL
D642 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D644 DIODE 1ZC43(Q) QDLZ001ZC43Q
D645 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D646 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D647 SCHOTTKY BARRIER DIODE ERB81-004 AERB81004***
D648 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
D649 ZENER DIODE MTZJT-7733B QDTB00MTZJ33
D650 ZENER DIODE MTZJT-776.2C QDTC0MTZJ6R2
D651 DIODE FR104-B NDLZ000FR104
D652 ZENER DIODE MTZJT-7724A QDTA00MTZJ24
D654 DIODE FR154 NDLZ000FR154
D655 ZENER DIODE MTZJT-776.8C QDTC0MTZJ6R8
D656 ZENER DIODE MTZJT-7716B QDTB00MTZJ16
D657 DIODE FR154 NDLZ000FR154
D658 ZENER DIODE MTZJT-775.6C QDTC0MTZJ5R6
D660 ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D667 SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D668 PCB JUMPER D0.6-P5.0 JW5.0T
D669 SCHOTTKY BARRIER DIODE ERA81-004Q QDLZRA81004Q
D670 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D671 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D676 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D801 ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D802 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D804 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D805 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D811 ZENER DIODE MTZJT-7720B QDTB00MTZJ20
D812 ZENER DIODE MTZJT-7720B QDTB00MTZJ20
D813 ZENER DIODE MTZJT-7720B QDTB00MTZJ20
D814 ZENER DIODE MTZJT-7720B QDTB00MTZJ20
ICS
IC603# PHOTO COUPLER LTV817MCF NPECLTV817MF
IC637 IC LD1117V NSZBA0SSS046
IC701 IC(AUDIO D/A) PCM1782DBQR NSZBA0TTY192
IC702 IC OP AMP NJM4558M(TE1)-#ZZZB QSZBA0TJR089
IC801 IC POWER AMP R2A15108SN QSZBA0THT074
IC7001 IC VIDEO ANALOG INTERFACE R2A11011FP
QFP 56PIN
QSZBA0RHT066
IC7301 IC SWITCHING TC4052BF(ELNF) QSZBA0TTS162
COILS
L1 CHOKE COIL 22µH-K LLBD00PKV021
L801 COIL RADIAL LHLP10NB220M 22µH LLF2200TU003
L802 COIL RADIAL LHLP10NB220M 22µH LLF2200TU003
L803 COIL RADIAL LHLP10NB220M 22µH LLF2200TU003
L804 COIL RADIAL LHLP10NB220M 22µH LLF2200TU003
L7802 PCB JUMPER D0.6-P5.0 JW5.0T
L7803 PCB JUMPER D0.6-P5.0 JW5.0T
TRANSISTORS
Q2 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q3 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q4 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q5 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q501 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q502 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q601# FET MOS 2SK3563(Q) QFWZ2SK3563Q
Q602# TRANSISTOR 2SC2120-O(TE2 F T) QQS02SC2120F
Q631 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q632 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q633 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q634 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q637 NPN TRANSISTOR POWER 2SC4881F HFE
MAX320
QQWZ2SC4881F
Ref. No. Description Part No.
Q638 NPN TRANSISTOR POWER 2SC4881F HFE
MAX320
QQWZ2SC4881F
Q639 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q645 TRANSISTOR 2SD400(E) QQUE002SD400
Q646 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q650 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q671 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q801 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q7201 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q7301 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q7302 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
RESISTORS
R1 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R2 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R5 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R6 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7 CHIP RES. 1/10W J 150k Ω RRXAJR5Z0154
R8 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R11 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R12 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R13 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R14 CHIP RES. 1/10W J 220k Ω RRXAJR5Z0224
R16 CHIP RES. 1/10W J 750 Ω RRXAJR5Z0751
R17 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R18 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R19 CHIP RES. 1/10W J 560 Ω RRXAJR5Z0561
R20 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R21 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R22 CHIP RES. 1/10W J 1.5k Ω RRXAJR5Z0152
R24 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R25 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R26 CHIP RES. 1/10W J 82 Ω RRXAJR5Z0820
R301 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R302 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R303 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R501 PCB JUMPER D0.6-P5.0 JW5.0T
R502 CHIP RES. 1/10W F 7.50 k Ω RRXAFR5H7501
R504 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R505 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R506 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R507 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R509 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R510 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R512 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R514 PCB JUMPER D0.6-P5.0 JW5.0T
R516 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R517 PCB JUMPER D0.6-P5.0 JW5.0T
R519 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R521 PCB JUMPER D0.6-P5.0 JW5.0T
R523 CHIP RES. 1/10W J 51k Ω RRXAJR5Z0513
R524 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R526 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R527 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R601# METAL RES. 2W J 0.39 Ω RN02JZPZ0R39
R603 PCB JUMPER D0.6-P5.0 JW5.0T
R604 CARBON RES. 1/4W J 390k Ω RCX4JATZ0394
R605 CARBON RES. 1/4W J 390k Ω RCX4JATZ0394
R606 CARBON RES. 1/4W J 390k Ω RCX4JATZ0394
R607 CARBON RES. 1/4W J 390k Ω RCX4JATZ0394
R609 CARBON RES. 1/4W J 5.6k Ω RCX4JATZ0562
R610 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
R611 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R612 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
Ref. No. Description Part No.
