Emerson LC320EM9 User Manual

20080213 13-5 A8AF1EL
FUNCTION CBA
IR SENSOR CBA
JUNCTION-A CBA
MUT CBA
INVERTER CBA
R7716 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7723 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7724 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7730 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7731 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7738 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7739 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7747 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7748 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7755 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7756 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7763 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7764 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7771 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7772 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7779 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7780 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7787 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7788 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
MISCELLANEOUS
B16 POW HEAT SINK A7120UH 1EM423993
B17 MODULE HEAT SINK PMC P7150UT 1EM423968
BC1 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC2 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC3 PCB JUMPER D0.6-P5.0 JW5.0T
BC4 CHIP INDUCTOR BK1608HS601-T LLC601NTU017
BC601 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC701 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC702 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC801 PCB JUMPER D0.6-P5.0 JW5.0T
BC802 PCB JUMPER D0.6-P5.0 JW5.0T
BC803 PCB JUMPER D0.6-P5.0 JW5.0T
BC804 PCB JUMPER D0.6-P5.0 JW5.0T
BC7206 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
JK7701 Y/C JACK YKF51-5646N JYEJ040JC001
JK7702 JACK SW RCA PCB S RCA-347HDT-02 JYRJ030YUQ01
JK7703 Y/C JACK YKF51-5646N JYEJ040JC001
JK7704 JACK SW RCA PCB S RCA-347HDT-02 JYRJ030YUQ01
JK7705 JACK RCA PCB S RCA-228H(NI)-01 JXRJ020YUQ07
JK7711 JACK RCA PCB S 03 RCA-347HT-03 JXRJ030YUQ01
JK7712 JACK SW RCA PCB S RCA-228H(2)NI-01 JYRJ020YUQ02
JK7713 JACK RCA PCB S 03 RCA-347HT-03 JXRJ030YUQ01
JK7714 JACK SW RCA PCB S RCA-228H(2)NI-01 JYRJ020YUQ02
JK7715 JACK RCA PCB S ORANGE 01/RCA-101H(OR) JXRJ010YUQ06
JS641 PCB JUMPER D0.6-P15.0 JW15.0T
JS651 PCB JUMPER D0.6-P5.0 JW5.0T
JS652 PCB JUMPER D0.6-P5.0 JW5.0T
L7 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
T601# TRANS POWER 8709 LTT2PC0KT032
TU1 TUNER UNIT UA023AF UTUNATSSP006
Ref. No. Description Part No.
FUNCTION CBA(MPS-3)
Consists of the following:
----------
CAPACITORS
C109 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C110 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
DIODE
D108 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
RESISTORS
R120 CARBON RES. 1/4W G 6.8k Ω RCX4GATZ0682
Ref. No. Description Part No.
R121 CARBON RES. 1/4W G 4.7k Ω RCX4GATZ0472
R122 CARBON RES. 1/4W G 2.7k Ω RCX4GATZ0272
R123 CARBON RES. 1/4W G 2.2k Ω RCX4GATZ0222
R124 CARBON RES. 1/4W G 1.5k Ω RCX4GATZ0152
R125 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R126 CARBON RES. 1/4W G 1.5k Ω RCX4GATZ0152
SWITCHES
SW108 TACT SWITCH SKQSAB SST0101AL038
SW109 TACT SWITCH SKQSAB SST0101AL038
SW110 TACT SWITCH SKQSAB SST0101AL038
SW111 TACT SWITCH SKQSAB SST0101AL038
SW112 TACT SWITCH SKQSAB SST0101AL038
SW113 TACT SWITCH SKQSAB SST0101AL038
SW114 TACT SWITCH SKQSAB SST0101AL038
Ref. No. Description Part No.
IR SENSOR CBA(MPS-4)
Consists of the following:
----------
CAPACITORS
C101 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C107 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
DIODES
D101 LED L-53HT NP4Z000L53HT
D102 LED 333GT/E NPHZ00333GTE
RESISTORS
R101 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R102 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R103 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R104 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R105 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
MISCELLANEOUS
CL101 WIRE ASSEMBLY 002 6PIN / 350MM / AWG26 WX1A8AF0-002
CL102 WIRE ASSEMBLY 003 3PIN / 140MM / AWG26 WX1A8AF0-003
RCV101 PHOTO LINK MODULE KSM-712TH2E USESJRSKK044
Ref. No. Description Part No.
JUNCTION-A CBA(MPS-5)
Consists of the following:
----------
CONNECTOR
CN101 242 SERIES CONNECTOR TUC-P06X-B1 WHT
ST
JCTUB06TG002
Ref. No. Description Part No.
MUT CBA
Consists of the following
1FSA10452
INVERTER CBA
JUNCTION-B CBA
----------
----------
Ref. No. Description Part No.
INVERTER CBA
Consists of the following:
----------
CAPACITORS
C1000 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1001 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1002 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1003 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
Ref. No. Description Part No.
