20080213 13-6 A8AF1EL
C1004 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1005 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C1006 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C1007 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C1008 CHIP CERAMIC CAP.(1608) B K 2.2µF/10V CHD1AK30B225
C1009 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1010 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1011 CHIP CERAMIC CAP.(1608) B K 0.47µF/10V CHD1AK30B474
C1012 CHIP CERAMIC CAP.(1608) B K 0.47µF/10V CHD1AK30B474
C1014 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1015 ELECTROLYTIC CAP. 470µF/35V M CE1GMZNDL471
C1016 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1017 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1018 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1019 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1020 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1021 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1022 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C1023 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C1032 ELECTROLYTIC CAP. 47µF/35V M CE1GMASDL470
C1040 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1044 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1046 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1061 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1062 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1063 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1064 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1065 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1066 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1067 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1101 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1103 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1104 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1105 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1106 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1107 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1111 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1112 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1113 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1114 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1115 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1116 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1117 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1161 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1162 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1163 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1164 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1165 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1166 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1167 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1211 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1212 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1213 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1214 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1215 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1216 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1217 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1261 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1262 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1263 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1264 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1265 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1266 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
Ref. No. Description Part No.
C1267 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1500 CHIP CERAMIC CAP.(1608) F Z 0.22µF/50V CHD1JZ30F224
C1502 CHIP CERAMIC CAP.(1608) F Z 0.22µF/50V CHD1JZ30F224
C1550 CHIP CERAMIC CAP.(1608) F Z 0.22µF/50V CHD1JZ30F224
C1552 CHIP CERAMIC CAP.(1608) F Z 0.22µF/50V CHD1JZ30F224
C1701 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1901# METALIZED FILM CAP. 0.47µF/250V CT2E474MS037
C1902# METALIZED FILM CAP. 0.47µF/250V CT2E474MS037
C1910 CAP ELE LS 470µF/200V/M/85 CA2D471V8006
C1930 CERAMIC CAP. BN 1000pF/2KV CCD3DKA0B102
C1931 POLYESTER FILM CAP. (PB FREE) 0.001µF/
100V J
CA2A102DT018
C1932 POLYESTER FILM CAP. (PB FREE) 0.027µF/
100V J
CA2A273DT018
C1933 POLYESTER FILM CAP. (PB FREE) 0.1µF/100V
J
CA2A104DT018
C1941 CERAMIC CAP. B K 0.01µF/1KV CCD3AKP0B103
C1970 POLYESTER FILM CAP. (PB FREE) 0.0022µF/
100V J
CA2A222DT018
C1980 CHIP CERAMIC CAP. F Z 0.01µF/50V CHD1JZ30F103
C1981 ELECTROLYTIC CAP. 0.47µF/50V M CE1JMASDLR47
C1990 CERAMIC CAP. B K 3300pF/500V CCD2JKS0B332
C1991# CAP ELE STD-85 4700µF/35V SL CE1GMZNDL472
CONNECTORS
CN1050 CONNECTOR PRINT OSU KW05-120-02-00 J30502KET001
CN1100 CONNECTOR PRINT OSU KW05-120-02-00 J30502KET001
CN1150 CONNECTOR PRINT OSU KW05-120-02-00 J30502KET001
CN1200 CONNECTOR PRINT OSU KW05-120-02-00 J30502KET001
CN1250 CONNECTOR PRINT OSU KW05-120-02-00 J30502KET001
CN1901 CONNECTOR B2P3-VH(LF)(SN) J3VH020JG001
DIODES
D1000 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1001 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1002 ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D1003 ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D1004 ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D1005 ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D1006 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1008 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D1021 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1042 ZENER DIODE MTZJT-7724B QDTB00MTZJ24
D1043 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1045 ZENER DIODE MTZJT-7724B QDTB00MTZJ24
D1046 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1060 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1061 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1062 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1063 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1064 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1065 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1066 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1067 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1068 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1110 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1111 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1112 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1113 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1114 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1115 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1116 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1117 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1118 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1160 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1161 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
Ref. No. Description Part No.
