Emerson LC320EM9 User Manual

20080213 13-7 A8AF1EL
D1162 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1163 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1164 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1165 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1166 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1167 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1168 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1210 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1211 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1212 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1213 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1214 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1215 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1216 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1217 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1218 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1260 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1261 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1262 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1263 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1264 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1265 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1266 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1267 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1268 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1501 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1502 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1503 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1550 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1551 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1552 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1553 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1702 ZENER DIODE MTZJT-773.3B QDTB0MTZJ3R3
D1901# DIODE 1N5406 NDLZ001N5406
D1902# DIODE 1N5406 NDLZ001N5406
D1903# DIODE 1N5406 NDLZ001N5406
D1904# DIODE 1N5406 NDLZ001N5406
D1930 ZENER DIODE MTZJT-7727B QDTB00MTZJ27
D1931 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D1932 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1933 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1934 DIODE 1ZC36(Q) QDLZ001ZC36Q
D1940 DIODE FAST RECOVERY FR157 NDLZ000FR157
D1970 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D1971 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D1980 ZENER DIODE MTZJT-7736B QDTB00MTZJ36
D1981 PCB JUMPER D0.6-P5.0 JW5.0T
D1982 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1990# DIODE SCHOTTKY FD867-15L QDWZFD86715L
D1991# DIODE SCHOTTKY FD867-15L QDWZFD86715L
D1992# DIODE SCHOTTKY FD867-15L QDWZFD86715L
D1994 DIODE 1ZC36(Q) QDLZ001ZC36Q
ICS
IC1001 IC INVERTER CONTROLLER OZ9966SN-B1-0-
TR/SSO
NSZBA0TTMC06
IC1500 IC BA10324AF-E2 QSZBA0TRM032
IC1550 IC BA10324AF-E2 QSZBA0TRM032
IC1930# PHOTO COUPLER LTV817MCF NPECLTV817MF
IC1931# PHOTO COUPLER LTV817MCF NPECLTV817MF
COILS
L1901# FILTER LLBG00ZY2015 LLBG00ZY2015
L1902# FILTER LLBG00ZY2015 LLBG00ZY2015
TRANSISTORS
Ref. No. Description Part No.
Q1002 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1020 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q1100 FET POWER MOS SMD NP22N055SLE-E1-AZ QF2ZNP22N055
Q1101 FET POWER MOS SMD NP22N055SLE-E1-AZ QF2ZNP22N055
Q1102 FET POWER MOS SMD NP22N055SLE-E1-AZ QF2ZNP22N055
Q1103 FET POWER MOS SMD NP22N055SLE-E1-AZ QF2ZNP22N055
Q1930# FET MOS 2SK3561(Q) IDSS100UA QFWZ2SK3561Q
Q1931 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1932 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q1970 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1971 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1972 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
RESISTORS
R1000 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1001 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1002 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1003 CHIP RES. 1/10W J 220k Ω RRXAJR5Z0224
R1005 CHIP RES. 1/10W F 160 k Ω RRXAFR5H1603
R1006 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1007 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1008 CHIP RES. 1/10W J 51k Ω RRXAJR5Z0513
R1009 CHIP RES. 1/10W F 1M Ω RRXAFR5H1004
R1010 CHIP RES. 1/10W F 120 k Ω RRXAFR5H1203
R1011 CHIP RES. 1/10W F 130k Ω RRXAFR5H1303
R1012 CHIP RES. 1/10W J 68k Ω RRXAJR5Z0683
R1013 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1014 CARBON RES. 1/4W J 51k Ω RCX4JATZ0513
R1015 CHIP RES.(1608) 1/10W F 5.1k Ω RRXAFR5H0512
R1020 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1041 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1045 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R1046 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R1047 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1048 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1050 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R1051 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R1052 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1053 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1060 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1061 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1062 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1063 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R1064 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1065 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1066 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1067 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R1068 CHIP RES. 1/10W F 6.8k Ω RRXAFR5H6801
R1069 CHIP RES. 1/10W F 6.8k Ω RRXAFR5H6801
R1070 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1071 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1100 CHIP RES. 1/10W J 33 Ω RRXAJR5Z0330
R1101 CHIP RES. 1/10W J 33 Ω RRXAJR5Z0330
R1102 CHIP RES. 1/10W J 33 Ω RRXAJR5Z0330
R1103 CHIP RES. 1/10W J 33 Ω RRXAJR5Z0330
R1110 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1111 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1112 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1113 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R1114 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1115 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1116 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1117 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
Ref. No. Description Part No.
