Emerson LC320EM9 User Manual

20080213 13-8 A8AF1EL
JUNCTION-B CBA
R1118 CHIP RES. 1/10W F 6.8k Ω RRXAFR5H6801
R1119 CHIP RES. 1/10W F 6.8k Ω RRXAFR5H6801
R1120 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1121 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1160 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1161 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1162 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1163 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R1164 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1165 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1166 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1167 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R1168 CHIP RES. 1/10W F 6.8k Ω RRXAFR5H6801
R1169 CHIP RES. 1/10W F 6.8k Ω RRXAFR5H6801
R1170 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1171 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1210 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1211 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1212 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1213 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R1214 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1215 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1216 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1217 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1218 CHIP RES. 1/10W F 6.8k Ω RRXAFR5H6801
R1219 CHIP RES. 1/10W F 6.8k Ω RRXAFR5H6801
R1220 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1221 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1260 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1261 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1262 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1263 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1264 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1265 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1266 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1267 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1268 CHIP RES. 1/10W F 6.8k Ω RRXAFR5H6801
R1269 CHIP RES. 1/10W F 6.8k Ω RRXAFR5H6801
R1270 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1271 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1500 CHIP RES. 1/10W F 47.0 k Ω RRXAFR5H4702
R1501 CHIP RES. 1/10W F 1.0k Ω RRXAFR5H1001
R1504 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1506 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1507 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1508 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1509 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1510 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1511 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1550 CHIP RES. 1/10W F 47.0 k Ω RRXAFR5H4702
R1551 CHIP RES. 1/10W F 1.0k Ω RRXAFR5H1001
R1554 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1555 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1556 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1557 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1558 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1559 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1560 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1561 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1703 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R1901# RES CARBON 1/2W J 1M Ω RCX2105DP006
R1902# CEMENT RESISTOR 5W K 2.2 Ω RW052R2PAK11
R1904# CEMENT RESISTOR 5W K 2.2 Ω RW052R2PAK11
Ref. No. Description Part No.
R1930 CARBON RES. 1/4W J 47 Ω RCX4JATZ0470
R1931 CARBON RES. 1/4W J 47k Ω RCX4JATZ0473
R1932 CARBON RES. 1/4W J 120 Ω RCX4JATZ0121
R1933 CARBON RES. 1/4W J 120 Ω RCX4JATZ0121
R1934 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R1936 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
R1937 METAL OXIDE FILM RES. 2W J 0.27 Ω RN02R27ZU001
R1939 CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
R1940 CARBON RES. 1/4W J 470k Ω RCX4JATZ0474
R1941 CARBON RES. 1/4W J 470k Ω RCX4JATZ0474
R1942 CARBON RES. 1/4W J 180k Ω RCX4JATZ0184
R1943 CARBON RES. 1/4W J 820k Ω RCX4JATZ0824
R1944 CARBON RES. 1/4W J 820k Ω RCX4JATZ0824
R1945 CARBON RES. 1/4W J 390k Ω RCX4JATZ0394
R1946 METAL OXIDE FILM RES. 2W J 47k Ω RN02473ZU001
R1947 METAL OXIDE FILM RES. 2W J 47k Ω RN02473ZU001
R1948 METAL OXIDE FILM RES. 2W J 47k Ω RN02473ZU001
R1949 CARBON RES. 1/4W J 120 Ω RCX4JATZ0121
R1970 CARBON RES. 1/4W J 150 Ω RCX4JATZ0151
R1971 CARBON RES. 1/4W J 3.9k Ω RCX4JATZ0392
R1973 CARBON RES. 1/4W G 150 Ω RCX4GATZ0151
R1974 CHIP RES. 1/10W F 5.6k Ω RRXAFR5H5601
R1975 CHIP RES. 1/10W F 6.8k Ω RRXAFR5H6801
R1976 CHIP RES. 1/10W F 6.8k Ω RRXAFR5H6801
R1977 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1980 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R1981 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1983 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1984 PCB JUMPER D0.6-P5.0 JW5.0T
R1985 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R1986 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R1987 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
MISCELLANEOUS
AC1901# AC CORD LP-11W&PT218P-K90A&S WAC0172LW020
B18 HEAT SINK PMP ASSEMBLY A8AF0UH 1EM425500
BC1001 PCB JUMPER D0.6-P5.0 JW5.0T
BC1931 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC1932 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
CL1000 WIRE ASSEMBLY 4PIN / 90MM / AWG26 WX1A8AF0-001
F1901# FUSE STC4A125V U/CT PAGE20CW3402
FH1901 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
FH1902 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
L7 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
SA1901# SURGE ABSORBER 470V+-10PER NVQZ10D471KB
T1050 TRANS INVERTER HVT-133 LTZ3PC0XB004
T1100 TRANS INVERTER HVT-133 LTZ3PC0XB004
T1150 TRANS INVERTER HVT-133 LTZ3PC0XB004
T1200 TRANS INVERTER HVT-133 LTZ3PC0XB004
T1250 TRANS INVERTER HVT-133 LTZ3PC0XB004
TM1901 EYELET TYPE D-1 0VM406868
TM1902 EYELET TYPE D-1 0VM406868
T1951# TRANS POWER 8708 LTT3PC0KT041
Ref. No. Description Part No.
JUNCTION-B CBA
Consists of the following:
----------
CONNECTOR
CN1000 242 SERIES CONNECTOR TUC-P04X-B1 WHT
ST
JCTUB04TG002
Ref. No. Description Part No.
