Emerson NetSure 501 AA0 Instruction Manual

2 Chapter 1 Overview
Dummy plate
AC input MCB
Load MCB
Load MCB
Rectifier
Battery MCB
Monitoring module
Positive terminals
Positive terminals
Figure 1.2 NetSure 501 AA0 system structure
Dummy plate
AC input MCB
Load MCB
Load MCB
Rectifier
Battery MCB
Monitoring module
Positive terminals
Positive terminals
Figure 1.3 NetSure 701 A51 (PS48300-3A/3200) system structure
Battery MCB
Positive terminals
Monitoring module
Load MCB
AC input MCB
Dummy plate
Rectifier
Figure 1.4 NetSure 701 A51 (PS48300-3A/3200-X2) system structure
System configuration
The configurations of the power supply system are described in Table 1-1.
NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack Power Supply System User Manual
