Emerson QuickPanel+ IC755C S06RD Series Quick Start Guide

Quick Start Guide Section 5
GFK-2893P Sep 2019
Product Certification & Installation Guidelines 37
clamp. Then close the retaining clamp to
fit the cable size.
Figure 5.3: Adjusting position of retaining
clamp
• USB retaining clamp for IC755CSW07CDACA
must be used in hazardous location
installations as follows:
1. Connect the USB retaining clamp plate.
Figure 5.4: USB retaining Clamp Plate
2. Connect the USB cable and insert the
retaining clamp into the retaining clamp
plate.
